— 18 —
4. C-In line CN (connection) type message reception test
This command will check the communication by CN type message. This operaton
will return the transmission data after reception data without any change.
Before performing this transmission test, set the ID No. & Baud rate by the Item
No.1 operation.
[Operation]
Press 8 4 n #2 . (whereas n = Machine ID No.)
ID No. = 1 ~ 9(ID No.0 is for the host computer.)
(10~32 are not possible to use.)
Note 1:To stop the test, press #2 key.
Note 2:To perform this test, the reception machine is necessary.
After operat ing this test, perform the CN type transmission command
on the transmission machine.
[Print sample (Normal end) ]
841 OK
[Print sample (Abnormal end) ]
841 ER83 01-0000
Error machine ID No.
Error code
Error block counter No.
5. C-In line CL (connection less) type message transmission test
This command will check the communication by CL type message. This operaton
will send the data to the all reception machines.
Before performing this transmission test, set the ID No. & Baud rate by the Item
No.1 operation.
[Operation]
Press 8 5 0 #2 .
Note 1: To stop the test, press #2 key.
Note 2: To perform this test, the reception machine is necessary. Before operat
ing this test, perform the CL type receprion command on the reception
machine.
