Casio KL-1500 - PARTS LIST; Z556-1 PCB ASSY; Z556-E4 PCB ASSY

PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
Z556-1 PCB ASS'Y
LSI1 2011 9527
LSI
T6C37 1 1 A
N LSI3 2012 0476
LSI
HN62321AFRM2 1 1 A
LSI2 2011 9520
LSI
CXK5864CM-10LL 1 1 A
IC2 2114 2436
Monolithic IC
BA12003 1 5 B
X1 2590 1435
Ceramic oscillator
EFOEC4004A4 1 10 C
N C5 2803 7821
Electrol
y
tic capacitor
RE3-16V222M-T2 1 5 C
N C4 2803 7807
Electrol
y
tic capacitor
ECEA0JKA101B 1 20 C
C17 2807 2707
Electrol
y
tic capacitor
RE3-16V101M-T2 1 20 C
J1 3501 5103
AC power jack
HEC3110-01-010 1 10 C
CN3 3501 6307
connector
S5B-PH-K-S 1 20 C
CN4 3501 7770
connector
10FE-ST 1 10 C
L1 3013 0602
Inductor
SBT-0180W 1 5 C
N SW1 3412 1449
Switch
EVQ PAC 04M 1 20 C
F1 2114 3227
IC protector
ICP-N25-T104 1 10 B
IC3,IC4 2116 0056
Comparator
BA10339F 2 10 B
IC1 2105 2331
Detector
S-80745AN-D9-T1 1 5 B
IC5 2105 2702
Re
g
ulator
S-81250PG-PD-T1 1 10 A
Q1 2254 0119
FET
2SJ132-Z 1 5 B
N Q3 2259 1827
Chip transistor
2SB1197K-Q, R-T146 1 20 B
Q2,Q4 2259 0889
Chip di
g
ital transistor
DTC144EKT-96 2 20 B
D2 2390 1442
Chip diode
MA152K-(TX) 1 20 C
D1 2390 1827
Chip diode
MA737-(TX) 1 10 C
C12,C13 2845 2030
Chip capacitor
MCH215C102KK 2 20 C
C1 2981 0168
Chip capacitor
MCH215C103KK 1 20 C
C8,C14 2845 2289
Chip capacitor
MCH215C471KK 2 20 C
C2,C3,C6,C7, 2845 1540
Chip capacitor
MCH212F104ZK 8 20 C
C9~C11,C15
C16 2845 1925
Chip capacitor
MCH312F105ZP 1 10 C
R23,R24 2792 0217
Chip resistor
MCR10EZHJ101 2 20 C
R25 2792 0815
Chip resistor
MCR10EZHJ221 1 20 C
R14 2792 0960
Chip resistor
MCR10EZHJ822 1 20 C
R15~R21 2792 0831
Chip resistor
MCR10EZHJ103 7 20 C
R28 2792 1051
Chip resistor
MCR10EZHJ222 1 20 C
R4 2730 0530
Chip resistor
MCR10EZHJ272 1 20 C
R2 2792 0942
Chip resistor
MCR10EZHJ332 1 20 C
R22,R29,R30 2792 0462
Chip resistor
MCR10EZHJ473 3 20 C
R3,R31 2792 0209
Chip resistor
MCR10EZHJ104 2 20 C
R26,R27 2792 0888
Chip resistor
MCR10EZHJ334 2 20 C
R1 2730 0549
Chip resistor
MCR10EZHJ225 1 20 C
N R8~R13 2795 4613
Chip resistor
MCR10EZHF6340 6 20 C
N R5 2795 4606
Chip resistor
MCR10EZHF2002 1 20 C
R6,R7 2795 1190
Chip resistor
MCR10EZHF1002 2 20 C
RA1,RA2 2775 1372
Chip network resistor
MNR34J5AJ563 2 20 C
VR1 2795 4620
Chip volume
MVR32HXBRN502 1 20 C
Z556-E4 PCB ASS'Y
LSI202 2001 7295
LSI
HD44102CH 1 1 B
LSI201 2001 7287
LSI
HD44105H 1 1 B
LCD 3335 5502
LCD
CD427-TS 1 1 B
VR201 2765 0798
Volume
RK09G-J11T-203B 1 1 C
R210~R215 2792 0807
Chip resistor
MCR10EZHJ470 6 20 C
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 15 —
