— 8 —
Check item Operation Display Note
RANK CHECK
(4 SW)
Check the rank of the thermal
head employed in the unit.
(RANK = A ~ D)
To return to the main menu,
press any key.
PRINT CHECK-1
(5 PR1)
Refer to the following figure-1.
When finished printing it will
return to the main menu.
PRINT CHECK-2
(6 COM)
To return to the main menu,
press any key.
PRINT CHECK-2
(7 PR2)
Refer to the following figure-2.
When finisned printing it will
return to the main menu.
CP CHECK
(8 CP)
Press after
plugging communication
cable to communication
jack and shorting TX and
RX.
To return to the main menu,
press any key.
VP CHECK
(9 VP)
TCON signal from CPU is H, voltage
VP is applied to the thermal head
and stepping motor.
Adjust the voltage to be 12 V ± 0.1
V. When pressing any key VP turns
off and will return to the main menu.
ALL ITEM CHECK
(0 ALL)
The 9 check items are
proceeded automatically by
pressing any key, according to
the following order.
RAM---LCD---KEY---SW---PR1---
COM---PR2---CP---VP
4
RANK C
TAPE 18
5
NOW PRINTING
DATA1
6
9
Vp ON
12 0.1V
0
7
NOW PRINTING
CASIO COMPUT
CASIO COMPUT
CASIO COMPUT
8
PR-1 (Normal printing result)
PR-2 (Normal printing result)
Figure-1
Figure-2
