11. PARTS LIST
N Item Code No. Parts Name Specification Q R
COMPONENTS
1 6407 9150 W TAPE A-L277 A313217-1 1 B
2 6390 0432 CAP V332 A310765B-1 1 B
N 3 6407 9010 CASSETTE COVER L-277 A110844-1 1 B
N 4 6407 9130 B COVER B-L277 A313211A-1 1 B
N 5 6418 8190 DP PAN A-Z579 A340266-4 1 B
N 6 6418 8200 DP PAN B-Z579 A340265-3 1 B
N 7 6407 9051 C FILM L277 A211298A-1 1 B
N 8 6407 9091 SPACER L277 A211315A-1 1 C
N 9 6405 2790 SW KEY A-L244 A413391-1 2 B
N 10 6407 9220 SW KEY B-L244 A413391-3 1 B
11 3122 2520 BUZZER KBS-15DA-5C-22 1 C
N 12 6407 9030 CASSETTE CASE L277 A110892-1 1 B
N 13 6407 9140 SLIDE SWITCH L277 A313213-1 2 C
N 14 6418 8292 UPPER CASE Z579 A110842B-5 1 C
N 15 6418 8301 RUBBER KEY Z579 A110845A-5 1 C
N 16 6413 9620 Z570-S1 ASS'Y A240143E*1 1 B
N 17 6418 8170 Z570-3 ASS'Y A340275*2 1 B
N 18 6413 9970 PC JOINER B-Z570 A440429-1 1 A
N 19 6418 8324 LOWER CASE Z579 A110843D-6 1 C
N 20 6329 7620 BATTERY SPRING A-G272 A33938-1 1 C
21 6396 8870 BATTERY SPRING B-L531AA C310675-1 1 C
22 6408 9950 RUBBER FOOT L277 A414533-1 4 X
23 6413 9570 CHASSIS ASS'Y A140100D*1 1 A
ZX570-1 PCB UNIT
N 24 6413 9640 Z570-2 ASS'Y A240146A*1 1 B
N 25 6418 8160 Z570-1 ASS'Y A240142M*3 1 B
N 26 6407 9330 FFC JOINER A414077-1 1 A
ZX570-1 ASS'Y
LSI1 2012 0385 LSI T6C37A 1 B
LSI4 2010 9499 LSI TC55257BFL-8510L 1 B
N X1 2590 1995 CERAMIC OSCILLATOR EF0EC8004S4 1 B
N C6 2803 7870 ELECTROLYTIC CAPACITOR RE2-6V222M-T4 1 B
C7 2807 2315 ELECTROLYTIC CAPACITOR RE3-10V101M-T2 1 B
N LSI3 2012 5504 LSI UPD23C4001EJGW-C64 1 B
IC2 2105 2331 MOS-IC S-80745AN-D9-T1 1 B
Q1 2259 0959 CHIP DIGITAL TRANSISTOR DTC114YKT-146 1 B
D1 2390 0364 SCHOTTKY DIODE MA713-TX 1 B
N 27 6408 3580 STRAND WIRE SUB ASS'Y A414306*1 1 C
The following electronic parts will be not supplied from CASIO.
R100
CHIP JUMPER MCR10EZHJ000 1
R15~16
CHIP RESISTOR MCR10EZHJ470 2
R13~14
CHIP RESISTOR MCR10EZHJ101 2
R9
CHIP RESISTOR MCR10EZHJ221 1
R11
CHIP RESISTOR MCR10EZHJ102 1
R10
CHIP RESISTOR MCR10EZHJ182 1
R4~5
CHIP RESISTOR MCR10EZHJ103 2
R1~3R12
CHIP RESISTOR MCR10EZHJ473 4
R7,R8
CHIP RESISTOR MCR10EZHJ334 2
RM3,RM10
CHIP NETWORK RESISTOR MNR14EOAJB470 8
Notes: N – New parts Essential
Q – Quantity used per unit Stock recommended
R – Rank Others
No stock recommended
R – A :
B :
C :
X :
— 14 —
