LK-127
– 24 –
1: LK-127_DI
2: LK-127_EU
3: LK-127_US
123
MAIN PCB
1 10368210 PCB UNIT/MAIN TK-RJM510419*001 1 1 1 B MDA1
CN8 10178633 WIRE/BLUE 1007TASC24100B4040 1 1 1 X for Speaker (+)
CN9 10366747 WIRE/WHITE 1007TASC24100W4040 1 1 1 X for Speaker (-)
VR1 69304870 VARIABLE RESISTOR EVND8AA03B53 1 1 1 X for LCD contrast
D1-D8 10276977 DIODE L1SS400T1G 8 8 8 X
IC4 10240586 IC XC6109N40ANR 1 1 1 X
IC1 10363062 LSI ML6756B32GAZ03A114 1 1 1 C
IC3 10222381 LSI ST7066U-0A-QG 1 1 1 C
IC2 10159709 LSI UPD65881GK-1019ETA 1 1 1 C
Q9 69300298 TRANSISTOR 2SC4081T106R 1 1 1 X
Q5-Q8 10209018 TRANSISTOR KTA501U-GR-RTK/P 4 4 4 X
Q1-Q4 10207076 TRANSISTOR KTC601U-GR-RTK/P 4 4 4 X
TH1 10138692 THERMISTOR NCP18XH103J03RB 1 1 1 X
X1 10070555 RESONATOR CSTCW20M0X51-R0 1 1 1 X
POWER & AMP PCB
2 10368211 PCB UNIT/POWER & AMP TK-RJM510421*001 1 1 1 C PSA1
CN205,CN206 10178633 WIRE/BLUE 1007TASC24100B4040 2 2 2 X for Speaker (+)
CN204,CN207 10366747 WIRE/WHITE 1007TASC24100W4040 2 2 2 X for Speaker (-)
J201 35015103 JACK/DC HEC3110-01-010 1 1 1 B
J202 10305218 JACK/PHONES JY-6316B*01-070 1 1 1 C
IC201 10300598 IC TA8227APL-D12-H-T 1 1 1 X
L202 10231919 COIL RB53-856396NP 1 1 1 X
L201 10231920 COIL RB53-856397NP 1 1 1 X
D203,D204 10261170 DIODE SRT14-A2 2 2 2 X
D206,D207 79114195 DIODE UDZSTE-175.6B 2 2 2 X
D201,D202 10371167 DIODE L1SS355T1G 2 2 2 X
Q204 10206676 TRANSISTOR KTC2026-Y-U/P 1 1 1 X
Q201 69300298 TRANSISTOR 2SC4081T106R 1 1 1 X
Q202 10217742 TRANSISTOR KTA1270-Y-AT/P 1 1 1 X
Q203 10209015 TRANSISTOR KTD863-GR-AT/P 1 1 1 X
N Item Code No. Parts Name Specification R Remarks
Q'ty
To Next Page
