LK-127
– 25 –
1: LK-127_DI
2: LK-127_EU
3: LK-127_US
123
N Item Code No. Parts Name Specification R Remarks
Q'ty
KEYBOARD PCB
3 10368208 PCB UNIT/KYA TK-RJM508609*002 1 1 1 C KYA1/KYA2
D801-D830,D832 10301580 DIODE LM1MA142WAT1G 31 31 31 X
4 69261580 SPONGE/35X150 M440499-1 1 1 1 X
5 69268840 FABRIC TAPE/4X10 M440684-1 3 3 3 X
6 10368212 PCB UNIT/LDA TK-RJM510423*001 1 1 1 C LDA1/LDA2, for White key
D501-D536 10302396 LED 1154SURDKB5/7.5-90 36 36 36 X
7 10263729 SPONGE/43X180 M441123-001V01 1 1 1 X
N 8 10453355 PCB UNIT/LD3 TK-M240428*012 1 1 1 C LD3, for Black key
LED451-LED458 10302396 LED 1154SURDKB5/7.5-90 8 8 8 X
N 9 10453356 PCB UNIT/LD4 TK-M240429*012 1 1 1 C LD4, for Black key
LED459-LED466 10302396 LED 1154SURDKB5/7.5-90 8 8 8 X
N 10 10453357 PCB UNIT/LD5 TK-M240430*012 1 1 1 C LD5, for Black key
LED467-LED475 10302396 LED 1154SURDKB5/7.5-90 9 9 9 X
KEYBOARD UNIT
11 10304700 WHITE KEY/CB TK-RJM507243*003 4 4 4 C
12 10304699 WHITE KEY/CS TK-RJM507244*003 1 1 1 C
13 10301442 BLACK KEY/10P RJM506595-009V02 2 2 2 C
14 10301443 BLACK KEY/5P RJM506595-010V02 1 1 1 C
15 10163902 RUBBER CONTACT/CB RJM503854-001V01 4 4 4 B
16 10163903 RUBBER CONTACT/CS RJM503855-001V01 1 1 1 B
PANEL UNIT
N 17 10451540 PLATE/DISPLAY RJM510316-006V02 1 1 1 X
18 10301435 KNOB/SLIDE SWITCH RJM503803-009V01 2 2 2 X
19 69095890 CONTACT/SLIDE SWITCH CSB-12D 2 2 2 X
20 10417026 FABRIC TAPE RJM511849-001V01 1 1 1 X
21 10417025 FABRIC TAPE RJM511833-001V01 1 1 1 X
22 10272509 LCD SDT-M4396-RP-0 1 1 1 X
23 10366853 RUBBER CONNECTOR RJM510317-001V01 2 2 2 X
N 24 10451350 RUBBER KEY/A RJM510262-003V01 1 1 1 X
N 25 10451351 RUBBER KEY/B RJM510264-003V01 1 1 1 X
To Next Page
