— 28 —
N Item Code No. Parts Name Specification Q'ty Price code Rank
1. Main PCB block
N 1 1011 1100 PCB ASSY /E268-1 E140376*14 1 A
F1 3631 0330 FUSE 237001 1 AD A
IC2 2120 7393 IC/RESET S-80728AN-Z 1 AD A
IC3 1002 4618 LSI UPD78044FGF177-3B9 1 BR A
IC4 2120 6253 IC/MOS LB1268 1 AG A
X1 2520 3445 OSCILLATOR/CRYSTAL C-002RX(M90-76) 1 AD A
X2 2801 8932 LOCK/CERAMIC CST4.19MGW 1 AC A
D1-4,8 2315 2682 DIODE 1SR35-100A-T-82 5 AA B
D5,6,9 2315 2689 DIODE 1S2075K-TD 3 AA B
D7 1001 9404 DIODE 1S2471T-77-T 1 AA B
Q1 2250 1036 TRANSISTOR 2SD2396(K) 1 AE B
Q2 2250 1022 TRANSISTOR 2SD1803(T) 1 AF B
Q3 2250 1029 TRANSISTOR 2SD1961(S) 1 AC B
Q4 2200 9141 TRANSISTOR 2SA933(K,P,Q,R)T93 1 AA B
Q6 2250 0847 TRANSISTOR/DIGITAL DTC143ZS-TP 1 AA B
Q7 2220 2456 TRANSISTOR 2SC945(K,P,Q,R)-T 1 AA B
ZD1 2315 2675 DIODE/ZENER RD6.8EB1-T1 1 AA B
ZD2 2315 2661 DIODE/ZENER RD36EB1-T1 1 AA B
ZD3 2315 2766 DIODE/ZENER RD24EB2-T1 1 AA B
ZD4 2315 2759 DIODE/ZENER RD4.3EB2-T1 1 AA B
ZD5 2315 2654 DIODE/ZENER RD3.3EB2-T1 1 AA B
N C19 1008 0945 DIODE/ZENER RD6.2ESAB1 1 B
2 2408 8219 TUBE/DISPLAY 10-MT-75GC 1 BJ B
3 1001 8619 STAND/L DISPLAY E341001-1 1 AC C
4 1001 8618 STAND/R DISPLAY E341002-1 1 AC C
BZ1 3240 2089 BUZZER PKM22EPT-2001 1 AE C
C11 2807 2735 CAPACITOR/ELECTROLYTIC RE2-50V4R7M-T2 1 AA C
C14,15 2818 0446 CAPACITOR/CERAMIC RT-HE40TKYB101K-T 2 AA C
C3 2807 2658 CAPACITOR/ELECTROLYTIC RE3-25V472M 1 AL C
C4,7 2807 2315 CAPACITOR/ELECTROLYTIC RE3-10V101M-T2 2 AA C
CN1 6246 2780 CONNECTOR SUB ASSSY E311971*1 1 AE C
CN2 3500 3371 CONNECTOR IL-G-2P-S3T2-E 1 AA C
CN4 3510 3465 CONNECTOR 5267-02A 1 AA C
CN6 3540 4759 CONNECTOR IMSA-9604S-21C 1 AC C
CN7 3500 1077 CONNECTOR 52011-0810 1 AC C
CN8 6246 2830 CONNECTOR SUB ASSSY E412181*1 1 AP C
C1,5,17 CAPACITOR/CERAMIC RT-HE12TKYB103K-T 3 X
C10,12 CAPACITOR/CERAMIC RT-HE40TKYB221K-T 2 X
C2,16,19,28,29,30 CAPACITOR/CHIP RT-DSTC50TKYR103K 4 X
C20,23,31 CAPACITOR/CHIP ECQ-B1H103-KF 3 X
C21,22 CAPACITOR/CERAMIC RT-HE40TKCH120J-T 2 X
C8,9,13,18,24-27 CAPACITOR/CERAMIC RT-HE60TKYB222K-T 7 X
R1,15,21-23 RESISTOR CR-25-1KOHM-J-T 5 X
R10,11,18-20 RESISTOR CR-25-100KOHM-J-T 5 X
R13 RESISTOR CR-25-330KOHM-J-T 1 X
R14 RESISTOR CR-25-470KOHM-J-T 1 X
R16 RESISTOR CR-25-560OHM-J-T 1 X
R17 RESISTOR CR-25-150OHM-J-T 1 X
R2 RESISTOR CRH100-FH11J-10R 1 X
R3 RESISTOR CRH100-FH11J-1R0 1 X
R4 RESISTOR CR-25-750OHM-J-T 1 X
R5 RESISTOR CR-25-100OHM-J-T 1 X
R6 RESISTOR CR-25-24KOHM-J-T 1 X
R7 RESISTOR CR-25-75OHM-J-T 1 X
R8 RESISTOR CR-25-2.2KOHM-J-T 1 X
R9 RESISTOR CR-25-4.7KOHM-J-T 1 X
SCREW 3X12 ZMC-3... 3 X
