Casio PCR-260B Service Manual

— 29 —
N Item Code No. Parts Name Specification Q'ty Price code Rank
2. Button block
5 6221 3988 CAP/L E210964-1 4 AB C
6 6221 4025 CAP/S E311103-1 15 AA C
7 6245 7250 BUTTON/1 E311792-1 1 AB C
8 6245 7260 BUTTON/2 E311792-2 1 AB C
9 6245 7270 BUTTON/3 E311792-3 1 AB C
10 6245 7280 BUTTON/4 E311792-4 1 AB C
11 6245 7290 BUTTON/6 E311792-5 1 AB C
12 6245 7300 BUTTON/7 E311792-6 1 AB C
13 6245 7310 BUTTON/8 E311792-7 1 AB C
14 6245 7320 BUTTON/9 E311792-8 1 AB C
15 6245 7330 BUTTON/0 E311792-9 1 AB C
16 6245 7340 BUTTON/. E311792-10 1 AB C
17 6245 7350 BUTTON/00 E311792-11 1 AB C
18 6245 7360 BUTTON/5 E311116-4 1 AB C
19 6246 7768 KEY TOP/L E210963A-4 4 AD B
20 6246 7810 KEY TOP/S E311101A-4 27 AA B
21 6247 3830 SPRING/COIL E411104A-1 4 AA B
22 6248 0990 RUBBER/CONTACT E411877A-1 31 AA B
23 6247 3837 SPRING/COIL E411104A-2 4 AA B
24 1001 8612 SHEET/COMMON E341006-1 1 AH B
25 1001 8611 SPACER E341005-1 1 AB C
26 1001 8610 FPC E341004-1 1 AR B
27 1001 8613 CHASSIS/KEY BOARD E341007-1 1 AE C
28 1001 8609 FLAME/KEYBOARD E240664-1 1 AT C
FEED 1002 7139 PLATE/S E240685-1 1 AA C
AC C 1002 7140 PLATE/S E240685-2 1 AA C
X / FOR
/ DATE TIME
-/ 1002 7142 PLATE/S E240685-4 1 AA C
PLU 1002 7143 PLATE/S E240685-5 1 AA C
# / 1002 7144 PLATE/S E240685-6 1 AA C
% / CLK# 1002 7145 PLATE/S E240685-7 1 AA C
RA 1002 7146 PLATE/S E240685-8 1 AA C
PO 1002 7147 PLATE/S E240685-9 1 AA C
CH 1002 7148 PLATE/S E240685-10 1 AA C
CHK / NS 1002 7149 PLATE/S E240685-11 1 AA C
SUB TOTAL 1002 7150 PLATE/S E240685-12 1 AA C
MD / ST 1002 7151 PLATE/S E240685-13 1 AA C
1002 7152 PLATE/S E240685-14 1 AA C
1002 7153 PLATE/S E240685-15 1 AA C
1002 7154 PLATE/L E341057-1 1 AA C
1002 7155 PLATE/L E341057-2 1 AA C
1002 7156 PLATE/L E341057-3 1 AA C
1002 7157 PLATE/L E341057-4 1 AA C
SCREW 3X8 ZMC-3..... 2 X
AA C1002 7141 PLATE/S E240685-3 1
ERR.
CORR
T/S1
T/S2
8
x 3
AMT
TEND
CA
/
DEPT
SHIFT
9
+ 4
-
10
5
7
- 2
6
+ 1
