Casio Privia PX-870 User Manual

EN-54
Getting Ready
PX-870
1. Install the music stand by inserting its pegs
into the holes in the top of the piano.
PX-770
1. Slide the music stand under the two bolts on
the top of the piano and then tighten the bolts.
Protective tape is affixed to the front edges of the
keyboard keys to protect them during shipment.
Remove the protective tape before using the Digital
Piano.
• Peel off the tape by pulling carefully towards you as
shown in the illustration.
• If some keys seem to be raised up after you remove
the tape, press down to return them to their normal
positions.
To install the music stand Removing the Protective Tape
from the Keyboard

Casio Privia PX-870 Specifications

General

Keyboard	88 keys, Tri-sensor Scaled Hammer Action Keyboard II
Touch Sensitivity	3 sensitivity levels, Off
Polyphony	256 notes
Tones	19 built-in tones
Speakers	12cm x 2, 4cm x 2
Amplifiers	20W + 20W
USB	Type B
Power Consumption	18W
Sound Source	AiR Sound Source
Acoustic Simulator	Damper Resonance, String Resonance
Effects	Reverb (4 types), Chorus (4 types), Brilliance, DSP
Lesson Function	Yes
Recorder	2 tracks, 5, 000 notes total
Metronome	0 to 9 beats; tempo range: 20 to 255
Transpose	25 steps (-12 semitones to +12 semitones)
Tuning	A4 = 415.5Hz to 440.0Hz to 465.9Hz
Pedals	3 pedals (damper, soft, sostenuto)
Connectors	2 x Headphones
Line Out	Yes
Power Source	AC adaptor: AD-E24250LW
Included Accessories	AC adaptor, Music Stand
Headphones	Stereo mini jack (3.5mm) x 2
