Casio Privia PX-S1100 User Manual

EN-17
Digital Piano Operations
■ To adjust the depth of the hall simulator effect
1. Perform step 1 under “To specify the Hall
Simulator type” to select a hall simulator
effect.
2. While holding down 4 SOUND MODE, use
the keyboard keys below to adjust hall
simulator depth.
• Effect depth can be set to a value in the range of 0 (no
effect) to 42 (maximum depth). As you use the
keyboard keys to change the setting, the reference
tone (page EN-10) will sound any time the value
becomes a multiple of 10 (10, 20, etc.)
3. After the setting is the way you want, release
4 SOUND MODE.
■ To specify the Surround type
1. While holding down 4 SOUND MODE, press
the F1 (Surround Type 1) or F{1 (Surround
Type 2) keyboard key.
2. Release 4 SOUND MODE.
Pressing this key: Does this:
C{1 Lowers the effect depth applied to the
Digital Piano sound source one level.
D1 Raises the effect depth applied to the
Digital Piano sound source one level.
C{1 + D1 Returns the effect depth applied to the
Digital Piano sound source to the
initial default setting.
C1
A0
C2 C3 C4 C5 C6 C7
C8
D1
C{1
C1A0 C2 C3 C4 C5 C6 C7
C8
F{1F1

Casio Privia PX-S1100 Specifications

General

USB port	Yes
Audio input	1
Bluetooth version	5.0
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Battery type	AA
Power source type	Battery
Power consumption (min)	10 W
Number of batteries supported	6
Demo songs quantity	10
Transposition range	0 - 2 octave(s)
Product color	White
Sound effects	Brilliance, Chorus
Tones quantity	18
RMS rated power	16 W
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	0, 9
Maximum polyphony (notes)	192
Number of transpose switches	12
Music memory capacity (songs)	60
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	232 mm
Width	1322 mm
Height	102 mm
Weight	11200 g
