Casio Privia PX-S1100 User Manual

EN-43
Configuring Settings
To change MIDI settings, hold down 3 FUNCTION as you press the keyboard keys shown below.
Configuring MIDI Settings
This setting:
Pressing
this key:
Does this:
Local Control
When this setting is turned off, performance information (MIDI data) is
sent from the Digital Piano, but no Digital Piano sound is output. This
setting is for when you only want to send MIDI data to an external device.
G6 Toggles between on and off.
Keyboard Channel
This setting specifies a channel from 1 through 16 as the MIDI channel
that can be used for sending data to an external device.
A}6 Lowers the Keyboard Channel by 1.
A6 Raises the Keyboard Channel by 1.
A}6 + A6 Returns the Keyboard Channel to its
initial default setting (1).
Hi-Reso Velocity MIDI Out
This setting enables/disables high-resolution MIDI output of touch
pressure (velocity) when keyboard keys are pressed.
B6 Toggles between enabled and disabled.
C1
A0
C2 C3 C4 C5 C6 C7
C8
G6: Local Control
A}6: Keyboard Channel (–)
A6: Keyboard Channel (+)
B6: Hi-Res Vel MIDI OUT

Casio Privia PX-S1100 Specifications

General

USB port	Yes
Audio input	1
Bluetooth version	5.0
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Battery type	AA
Power source type	Battery
Power consumption (min)	10 W
Number of batteries supported	6
Demo songs quantity	10
Transposition range	0 - 2 octave(s)
Product color	White
Sound effects	Brilliance, Chorus
Tones quantity	18
RMS rated power	16 W
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	0, 9
Maximum polyphony (notes)	192
Number of transpose switches	12
Music memory capacity (songs)	60
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	232 mm
Width	1322 mm
Height	102 mm
Weight	11200 g
