Digital Piano Operations
EN-24
■ To change the octaves of the duet keyboards
1.
Hold down 3 FUNCTION.
• Do not release 3 FUNCTION until step 3, below.
2.
Use the keyboard keys below to change the
octaves of the left-side and right-side
keyboards.
• You can shift the octave of each keyboard within the
range of –2 to +2 octaves.
Setting Example
Pressing the D6 keyboard key once will configure the
keyboard octaves as shown below.
3.
When the octave settings of the keyboards are
the way you want, release 3 FUNCTION.
You can change the scale of the keyboard from the standard
equal temperament to another tuning that is more suitable for
playing Indian music, Arabic music, classical music, etc. You
can select from among the 17 preset scales described below.
■ To change the scale
1.
While holding down 3 FUNCTION, press a
keyboard key from C3 through E4.
• Pressing a keyboard key changes to the applicable
scale as shown in the table below.
2.
Release 3 FUNCTION.
Pressing
this key:
Does this:
C{6 Lowers the left-side keyboard one octave.
D6 Raises the left-side keyboard one octave.
C{6 + D6 Returns the range of the left-side keyboard to
its initial default setting.
E}6 Lowers the right-side keyboard one octave.
E6 Raises the right-side keyboard one octave.
E}6 + E6 Returns the range of the right-side keyboard
to its initial default setting.
Left keyboard Right keyboard
1 octave higher than initial setting Unchanged
Changing the Scale Tuning
(Temperament) of the Keyboard
Key Setting Value Scale Name
C3 0 Equal Temperament
C{31Pure Major
D3 2 Pure Minor
E}3 3 Pythagorean
E3 4 Kirnberger 3
F3 5 Werckmeister
F{3 6 Mean-Tone
G3 7 Rast
A}38Bayati
A3 9 Hijaz
B}3 10 Saba
B3 11 Dashti
C4 12 Chahargah
C{4 13 Segah
D4 14 Gurjari Todi
E}4 15 Chandrakauns
E4 16 Charukeshi
C1A0 C2 C3 C4 C5 C6 C7 C8
C3 D3 E}3E3 F3 G3A}3C{4D4 E4E}4C4A3 B}3B3F{3C{3
0 2 4 5 7 9 11 12 14 16
1 3 6 8 10 13 15
