Casio Privia PX-S1100 User Manual

EN-40
Configuring Settings
You can configure separate Upper2 and Lower (bass) part settings for the following items: volume, pitch, damper pedal effect
enable/disable. To configure these settings, hold down 8 GRAND PIANO as you press the keyboard keys shown below.
*1 You can set the volume within the range of 0 to 42.
*2 The reference tone (page EN-10) will sound any time the setting value becomes a multiple of 10 (10, 20, etc.)
Configuring Upper2 Part and Lower Part Settings
This setting:
Pressing
this key:
Does this:
Upper2 Volume
Adjusts the volume of the Upper2 part.
C{4 Lowers the Upper2 part volume by 1.
*1*2
D4 Raises the Upper2 part volume by 1.
*1*2
C{4 + D4 Returns the volume of the Upper2 part to the initial default
setting.
Upper2 Detune
Raises or lowers the pitch of the Upper2 part, relative
to the Upper1 part, within the range of ±99 cents
F4 Lowers the pitch of the Upper2 part one cent.
*2
F{4 Raises the pitch of the Upper2 part one cent.
*2
F4 + F{4 Makes the pitch of the Upper2 part identical to the pitch of
the Upper1 part (default).
Upper2 Damper
Toggles application of the damper pedal effect to the
Upper2 part between enabled and disabled.
G4 Toggles between enabled and disabled.
Lower Volume
Specifies the Lower part volume.
A}4 Lowers the Lower part volume by 1.
*1*2
A4 Raises the Lower part volume by 1.
*1*2
A}4 + A4 Returns the Lower part volume to the initial default setting.
Lower Detune
Raises or lowers the pitch of the Lower part, relative
to the Upper1 part, within the range of ±99 cents.
B}4 Lowers the pitch of the Lower part one cent.
*2
B4 Raises the pitch of the Lower part one cent.
*2
B}4 + B4 Makes the pitch of the Lower part identical to the pitch of the
Upper1 part (default).
Lower Damper
Toggles application of the damper pedal effect to the
Lower part between enabled and disabled.
C5 Toggles between enabled and disabled.
C1
A0
C2 C3 C4 C5 C6 C7 C8
C{4: Upper2 Volume (–)
D4: Upper2 Volume (+)
F4: Upper2 Detune (–)
G4: Upper2 Damper
C5: Lower Damper
B4: Lower Detune (+)
B}4: Lower Detune (–)
A4: Lower Volume (+)
A}4: Lower Volume (–)
F{4: Upper2 Detune (+)

Casio Privia PX-S1100 Specifications

General

USB port	Yes
Audio input	1
Bluetooth version	5.0
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Battery type	AA
Power source type	Battery
Power consumption (min)	10 W
Number of batteries supported	6
Demo songs quantity	10
Transposition range	0 - 2 octave(s)
Product color	White
Sound effects	Brilliance, Chorus
Tones quantity	18
RMS rated power	16 W
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	0, 9
Maximum polyphony (notes)	192
Number of transpose switches	12
Music memory capacity (songs)	60
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	232 mm
Width	1322 mm
Height	102 mm
Weight	11200 g
