Casio Privia PX-S1100 User Manual

EN-41
Configuring Settings
You can use the keyboard keys in this section to adjust the volumes of keyboard play, song playback, and externally input audio.
To adjust, hold down 3 FUNCTION as you press the keyboard keys shown below.
*1 The reference tone (page EN-10) will sound any time the setting value becomes a multiple of 10 (10, 20, etc.)
*2 Input audio of audio data (WAV) stored on a USB flash drive.
Adjusting the Volume Balance
This setting:
Pressing
this key:
Does this:
Keyboard Volume
Adjusts the volume of keyboard play relative to the
overall volume level within the range of 0 (muted) to
42 (maximum).
C5 Lowers the keyboard volume by 1.*
1
C{5 Raises the keyboard volume by 1.*
1
C5 + C{5 Returns the keyboard volume to its initial default setting.
MIDI Song Volume
Adjusts the volume of song (built-in songs, user songs,
MIDI recorder song, USB flash drive songs) playback
relative to the overall volume level within the range of
0 (muted) to 42 (maximum).
D5 Lowers the MIDI song volume by 1.*
1
E}5 Raises the MIDI song volume by 1.*
1
D5 + E}5 Returns the MIDI song volume to its initial default setting.
Audio Song Playback Volume
Adjusts the playback volume of audio songs*
2
relative
to the overall volume level within the range of 0 (muted)
to 42 (maximum).
E5 Lowers the audio song playback volume by 1.*
1
F5 Raises the audio song playback volume by 1.*
1
E5 + F5 Returns the audio song playback volume to its initial
default setting.
Bluetooth Audio Playback Volume
Adjusts the Bluetooth audio playback volume relative to
the overall volume level within the range of 0 (muted) to
42 (maximum).
G5 Lowers the Bluetooth audio playback volume by 1.*
1
A}5 Raises the Bluetooth audio playback volume by 1.*
1
G5 + A}5 Returns the Bluetooth audio playback volume to its initial
default setting.
C1
A0
C2 C3 C4 C5 C6 C7
C8
C5: Keyboard Volume (–)
C{5: Keyboard Volume (+)
E5: Audio Song Volume (–)E}5: MIDI Song Volume (+)
D5: MIDI Song Volume (–) F5: Audio Song Volume (+)
G5: Bluetooth Audio Volume Level (–)
A}5: Bluetooth Audio Volume Level (+)

Casio Privia PX-S1100 Specifications

General

USB port	Yes
Audio input	1
Bluetooth version	5.0
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Battery type	AA
Power source type	Battery
Power consumption (min)	10 W
Number of batteries supported	6
Demo songs quantity	10
Transposition range	0 - 2 octave(s)
Product color	White
Sound effects	Brilliance, Chorus
Tones quantity	18
RMS rated power	16 W
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	0, 9
Maximum polyphony (notes)	192
Number of transpose switches	12
Music memory capacity (songs)	60
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	232 mm
Width	1322 mm
Height	102 mm
Weight	11200 g
