Casio Privia PX-S1100 User Manual

EN-49
Linking with a Smart Device (APP Function)
■ Using a Cable to Connect the Digital Piano with a Smart Device
1. Referring to “To download the smart device app” (page EN-48), install the app on the smart device.
2. Use a commercially available USB cable to connect the smart device port to the Digital Piano bk USB
Type B port.
• After connecting the smart device to the Digital Piano, use the smart device app to perform operations. For details about
operations, refer to the user documentation of the app.
• Put the mobile device you will connect with into its Airplane Mode or otherwise disable device communications.
• When connecting a smart device to the Digital Piano, do not connect both a USB cable and an audio cable at the same
time.
• Connect using a USB cable that is no more than two meters long.

Casio Privia PX-S1100 Specifications

General

USB port	Yes
Audio input	1
Bluetooth version	5.0
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Battery type	AA
Power source type	Battery
Power consumption (min)	10 W
Number of batteries supported	6
Demo songs quantity	10
Transposition range	0 - 2 octave(s)
Product color	White
Sound effects	Brilliance, Chorus
Tones quantity	18
RMS rated power	16 W
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	0, 9
Maximum polyphony (notes)	192
Number of transpose switches	12
Music memory capacity (songs)	60
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	232 mm
Width	1322 mm
Height	102 mm
Weight	11200 g
