A-2
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
kk .... Note Number = 00H to 7FH
vv .... Note Off Velocity = 00H to 7FH
Remarks
Note Off Velocity value is ignored.
Send
Format
417A-E–068A
MIDI Data Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
mm .. Data entry MSB value for the parameter that is se-
lected by RPN and NRPN
ll ....... Data entry LSB value for the parameter that is se-
lected by RPN and NRPN
Items marked “★” are receive only.
Channel Messages
Note Messages
Note Off
Recognition
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
kk .... Note Number = 15H to 6CH
vv .... Note Off Velocity = 40H
Note On
Recognition
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
kk .... Note Number = 00H to 7FH
vv .... Note Off Velocity = 00H to 7FH
Send
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
kk .... Note Number = 15H to 6CH
vv .... Note Off Velocity = 01 to 7FH
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
mm .. Bank Number MSB = 00H, 02H, 03H, 10H, 18H
ll ....... Bank Number LSB = 00H
Send
A Bank Select message is sent at the same time when you
select a tone on the instrument.
Modulation Wheel
★
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Modulation Depth = 00H to 7FH
Portamento Time
★
Format
Control Change
Bank Select
Format
n ....... Voice Channel Number = 0H to FH (Ch1 to Ch16)
vv .... Portamento Time = 00H to 7FH
Data Entry
Format
Byte 1 Byte 2 Byte 3
8nH kkH vvH
9nH kkH 00H
Byte 1 Byte 2 Byte 3
BnH 01H vvH
Byte 1 Byte 2 Byte 3
BnH 05H vvH
Byte 1 Byte 2 Byte 3
BnH 00H mmH (Bank Select MSB)
BnH 20H llH (Bank Select LSB)
Byte 1 Byte 2 Byte 3
BnH 06H mmH (Data Entry MSB)
BnH 26H llH (Data Entry LSB)
Byte 1 Byte 2 Byte 3
8nH kkH vvH
Byte 1 Byte 2 Byte 3
9nH kkH vvH
Byte 1 Byte 2 Byte 3
9nH kkH vvH
