Casio PX-300

— 25 —
N Item Parts code Parts Name Specification Q
Price
Code
R Remarks
E201 69324021 RELAY G5PA-28DC5V 1 AT X
IC201 10040646 IC TC74HCT04AF(EL) 1 AB X
IC202 69320061 IC PQ1CG21H2FZ 1 AO X
IC203 10062671 IC LA4636 1 AV X
L201 10071755 COIL R187-860400 1 AF X
L202,203 10056228 COIL R2318-RB53-856397 2 AB X
Jack PCB PSB4
N 3 10143172 PCB ASSY/JACK TK-RJM503531*001 1 AZ C
CN501,502 35800692 CONNECTOR B2B-EH 2 AA X
CN503 35015551 CONNECTOR B8B-PH-K-S 1 AA X
N J501,502,504 69325358 CONNECTOR JY-6314-01-130 3 AA X
J503,505,506 69325081 CONNECTOR JY-6314-01-030 3 AB X
L501-506 10056228 COIL R2318-RB53-856397 6 AB X
Console PCB
N 4 10143183 PCB ASSY/CONSOLE TK-RJM503526*001 1 CP B CNA1,CNA2
N D601-608,626,627 10136861 LED LT2P31-81-M181-S01 10 AA X
N D610-625 10136862 LED LT5J34-43-M181-S20 16 AA X
Q601-610,614-619 10047535 TRANSISTOR RN2205(TPE4) 16 AA X
Q611-613 10047532 TRANSISTOR 2SC5720(TPE4) 3 AA X
SW601-627 10096077 SWITCH SKQNADD010 27 AA X
CN602 10127509 HARNESS SCN-5P-67-M412 1 AO X
VR601 10122556 VARIABLE R RK09K12C0D1A 1 AL X
Key board assy
5 10133488 PCB ASSY/KEY TK-RJM503365*001 1 BI C KYA1,KYA3
D801-854,923-976 10079928 DIODE 1SS133TA 108 AA X
6 10133482 PCB ASSY/KEY TK-RJM503366*001 1 BC C
D855-922 10079928 DIODE 1SS133TA 68 AA X
CN803 35017294 CONNECTOR 30FMZ-ST 1 AF X
7 10133656 KY-RUBBER-AG-CPK RJM502920-001 7 AK B
8 10133635 KY-RUBBER-GC-CPK RJM502921-001 1 AG B
9 10135317 B-KEY-CPK RJM502797-001V01 36 AC C
10 10135426 W-KEY-CEGB-CPK RJM502862-001V01 7 AT C
11 10135427 W-KEY-DFA-CPK RJM502863-001V01 7 AQ C
12 10135428 W-KEY-B-CPK RJM502794-001V01 1 AG C
13 10135429 W-KEY-SA-CPK RJM502795-001V01 1 AJ C
14 10135430 W-KEY-SC-CPK RJM502796-001V01 1 AJ C
15 10135435 HAMMER-ASSY-W1 TK-RJM503155*001 13 AL C
16 10135436 HAMMER-ASSY-W2 TK-RJM503216*001 13 AL C
17 10135437 HAMMER-ASSY-W3 TK-RJM503217*001 13 AL C
18 10135438 HAMMER-ASSY-W4 TK-RJM503218*001 13 AL C
19 10135439 HAMMER-ASSY-B1 TK-RJM503219*001 9 AK C
20 10135440 HAMMER-ASSY-B2 TK-RJM503220*001 9 AK C
21 10135442 HAMMER-ASSY-B3 TK-RJM503221*001 9 AK C
22 10135443 HAMMER-ASSY-B4 TK-RJM503222*001 9 AK C
23 10129909 NUT/SUPPORT RJM503163-001V01 4 AC X
40 10153739 KEY UNIT TK-RJM503153A*002 1 EG C
42 1013 5958 CABLE N30195B1B05-UL2896 1 AG C
Case unit
24 10133640 PLATE/DISPLAY RJM502914-001V01 1 AA B
N 25 10143181 SP BLOCK L TK-RJM503150*003 1 AO C
N 26 10143182 SP BLOCK R TK-RJM503151*003 1 AO C
27 10135396 SPEAKER S0612J46 2 AY C
28 10127524 HARNESS EH-2P-20-M412 2 AB C
Notes: N- New parts R -A: Essential
Q- Quantity used per unit B: Stock recommended
R- Rank C: Others
X: No stock recommended
