7.26.1 Pitch Bend Sensitivity
Message Format: BnH 64H 00H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(00H - 18H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Transmit Sent when Bend Range of any part is changed.
Receive Receipt changes Bend Range of the corresponding part.
7.26.2 Fine Tune
Message Format: BnH 64H 01H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when the fine tune of any part is changed.
Receive Receipt changes the fine tune of the corresponding part.
7.26.3 Coarse Tune
Message Format: BnH 64H 02H
BnH 65H 00H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: MSB Value(28H - 58H)
ll: LSB Value(Transmit:00H, Receive:Ignored)
Transmit Sent when the coarse tune of any part is changed.
Receive Receipt changes the coarse tune of the corresponding part. Does not affect sound source
operation when the Timbre Type (see “About the Timbre Type” in “8 Program Change”) is Drum.
7.26.4 Null
Message Format: BnH 64H 7FH
BnH 65H 7FH
n: MIDI Channel Number
