Data Receiver Data Sender Operation
(External Device) (This Instrument)
SBS(HBR) -----> Session Start
Request
<----- ACK Acknowledge
HBR -----> Send Request (Start
Sub Session)
<----- HBS Send Packet
ACK -----> Acknowledge
<----- HBS Send Packet
ACK -----> Acknowledge
<----- HBS Send Packet
ACK -----> Acknowledge
:
Send Other Packet
:
ACK -----> Acknowledge
<----- ESS End Data (End Sub
Session)
:
Other Sub Session
:
EBS -----> End of Session
19.3.8 Example: Data send to Instrument from external device
Data Sender Data Receiver Operation
(External Device) (This Instrument)
SBS(HBS) -----> Session Start
Request
<----- ACK Acknowledge
HBS -----> Send Packet
<----- ACK Acknowledge
HBS -----> Send Packet
<----- ACK Acknowledge
HBS -----> Send Packet
<----- ACK Acknowledge
:
Send Other Packet
:
ESS -----> End of Data
:
Other Sub Session
:
EBS -----> End of Session
