Casio PX-700 User Manual

– 23 –
1
2
3
4
5
PX-720_BLACK_DI_120V
PX-720_BLACK_DI_230V
PX-720_BLACK_EU
PX-720_BLACK_UK
PX-720_BLACK_US
6
7
8
9
10
PX-720_CHERRY_DI_120V
PX-720_CHERRY_DI_230V
PX-720_CHERRY_EU
PX-720_CHERRY_UK
PX-720_CHERRY_US
N Item Parts Code Parts Name Specification QTY
Price
Code
R Remarks
MAIN PCB
N 1 10213950 PCB ASSY/MAIN TK-RJM506265*001 1 DK A
BT 10209154 BATTERY/LITHIUM CR2032T6
X
1 AF C
N CN5 10212694 HARNESS SMP-5P-43-M406 1 AE
X
D2 10133383 DIODE 02DZ2.7-Z
(
TPH3
)
1 AA
X
D3 10098748 DIODE 02DZ5.6-Y
(
TPH3
)
1 AA
X
D4,D5,D6 10009218 DIODE 1SS400TE61 3 AA
X
D1 23902576 DIODE RB501V-40TE-17 1 AB
X
F8,F9 10122975 NETWORK/R-C EZASSB516BJ 2 AA C
F2,4,5,6,7,10,11 10122976 NETWORK/R-C EZASTB63ABJ 7 AA C
F3 30251862 EMI FILTER NFM51R00P206 1 AC
X
IC8,13 10211950 I.C NJM2068M-D
(
TE1
)
2 AC C
IC5 10175415 C-MOS IC R1151N001C-TR-FB 1 AN C
IC12 10197798 IC TC74LCX138FT
(
EL.K
)
1 AI C
IC16 10197802 IC TC74VHCT08AFT
(
EL.K 1 AE C
IC9 10197553 IC TC7S04FU
(
TE85L.F
)
1 AA C
IC10 10137770 IC TC7S08FU
(
TE85L.F
)
1 AA C
IC6 10197554 IC TC7SZ126FU
(
TE85L.F 1 AE C
IC15 10195928 LSI UPD63200GS-E1-
A
1A
X
X
Q1 22592764 TRANSISTOR 2SB1188T100Q 1 AB
X
Q4 22530715 TRANSISTOR 2SD1664T100Q 1 AA
X
Q2 10202670 TRANSISTOR KTA2014-GR-RTK/P 1 AA
X
Q3 10207675 TRANSISTOR KTC4075-GR-RTK/P 1 AA
X
X1 10208977 RESONATOR SSM1638400F16FSFZ8 1 AC
X
N D7 10215910 DIODE 02DZ6.8-Y
(
TPH3,F
)
1 AA
X
Sub PCB PS
N 2 10213948 PCB ASSY/PSA TK-RJM506268*001 1 C
X
C
D201,D206 10209003 DIODE 1N5822-F100 2 AB
X
D213 10201501 IC PC900V0NSZXF 1 AG
X
E202 10211947 RELAY G5PA-28DC5V
(
PF
)
1 AN C
IC201 10203081 IC LA4636-E 1 AV
X
IC202 10201503 IC PQ1CG21H2FZH 1 AO
X
IC203 10209159 IC SN74HCT04AN 1 AC
X
N L205 10208248 COIL R187-860400NP 1 AC
X
N L204 10206672 COIL R2318-RB53856396NP 1 AA
X
N L201,202,203 10206680 COIL R2318-RB53856397NP 3 AA
X
D208 10209014 DIODE 1S4
(
26MM
)
1 AA
X
D202,204,
205,212
10079928 DIODE 1SS133TA 4 AA X
D203 10132124 ZENER DIODE DZ8.2BSBTA 1 AA
X
Q202 10025042 TRANSISTOR 2SD1468STPR 1 AA C
Q205 10209017 TRANSISTOR KTA1267-GR-AT/P 1 AA C
Q201,203,204,
206,208
10206673 TRANSISTOR KTC3199-GR-AT/P 5 AA C
CONSOLE
N 3 10213949 PCB ASSY/CNA4 TK-RJM506280*001 1 AQ C
L405 10206672 COIL R2318-RB53856396NP 1 AA
X
L403,L404 10206680 COIL R2318-RB53856397NP 2 AA
X
N 4 10213947 PANEL ASSY/CONSOLE TK-RJM505993*001 1 BD C
Notes: Q- Quantit
y
p
er uni
t
R- Ran
k

Casio PX-700 Specifications

General

Built-in Songs	60
Speakers	12cm x 2
Amplifier Output	8W + 8W
Power Consumption	18W
Polyphony (Maximum)	128
Digital Effects	Reverb (4 types), Chorus (4 types)
Transpose	±1 octave (–12 to +12 semitones)
Tuning	Yes (A4 = 415.5Hz to 465.9Hz)
Pedals	soft, sostenuto
Terminals	Headphone (Stereo standard jack) x 2
Power Supply	AC Adaptor (AD-A12150LW)
Included Accessories	music stand
Metronome	Beats: 0, 1, 2, 3, 4, 5 (Tempo range: quarter note = 30 to 255)
