Casio PX-700 User Manual

– 24 –
1
2
3
4
5
PX-720_BLACK_DI_120V
PX-720_BLACK_DI_230V
PX-720_BLACK_EU
PX-720_BLACK_UK
PX-720_BLACK_US
6
7
8
9
10
PX-720_CHERRY_DI_120V
PX-720_CHERRY_DI_230V
PX-720_CHERRY_EU
PX-720_CHERRY_UK
PX-720_CHERRY_US
N Item Parts Code Parts Name Specification QTY
Price
Code
R Remarks
KEY BOARD UNI
T
5 10208264 PCB ASSY/KEY TK-RJM506061*001 1 CI C
D801-854,
923-976
10079928 DIODE 1SS133TA 108 AA X
D855-922 10079928 DIODE 1SS133TA 68 AA
X
N CN803 10211732 CONNECTOR 30FMZ-ST
(
LF
)(
SN
)
1 AG
X
6 37195442 CABLE N30315B1B05-UL2896 1 AO C
7 10133656 RUBBER/CONTACT/AG RJM502920-001V01 7 AK B
8 10133635 RUBBER/CONTACT/GC RJM502921-001V01 1 AG B
9 10135317 BLACK KEY RJM502797-001V01 36 AC C
10 10135426 WHITE KEY/CEGB RJM502862-001V01 7 AT C
11 10135427 WHITE KEY/DFA RJM502863-001V01 7 AQ C
12 10135428 WHITE KEY/B RJM502794-001V01 1 AG C
13 10135429 WHITE KEY/SA RJM502795-001V01 1 AJ C
14 10135430 WHITE KEY/SC RJM502796-001V01 1 AJ C
15 10208265 HAMMER ASSY/W1 TK-RJM506035*001 13 AF C
16 10208266 HAMMER ASSY/W2 TK-RJM506036*001 13 AF C
17 10208267 HAMMER ASSY/W3 TK-RJM506037*001 13 AF C
18 10208269 HAMMER ASSY/W4 TK-RJM506038*001 13 AF C
19 10208275 HAMMER ASSY/B1 TK-RJM506039*001 9 AE C
20 10208281 HAMMER ASSY/B2 TK-RJM506040*001 9 AE C
21 10208286 HAMMER ASSY/B3 TK-RJM506041*001 9 AE C
22 10208290 HAMMER ASSY/B4 TK-RJM506042*001 9 AE C
N 23 10204304 CHASSIS/KEY RJM505515-001V01 1 B
X
C
N 24 10213920 KEY UNIT TK-RJM506362*001 1 EC B
MAIN CASE UNI
T
N 25 10213944 BOARD ASSY/TOP TK-RJM505995*001 1 CI C
N 26 10214383 BACK BOARD RJM505679-001V01 1 BH
X
N 27 10213943 COVER ASSY/KEY TK-RJM505994*001 1 DG C
N 28 10214305 HINGE RJM505888-001V01 3 AH C
N 29 10211850 GEAR RJM505897-001V01 2 AA C
N 30 10213955 COVER ASSY/FRONT TK-RJM506319*001 1 CL C
N 31 10211851 SLIDE CAP RJM505899-001V01 2 AA C
N 32 10213945 DAMPER ASSY TK-RJM506119*001 2 AT C
N 33 10211856 BOX/PCB RJM505923-001V01 1 AO
X
N 34 10214297 BRACKET/MIDI RJM506019-001V01 1 AC
X
N 35 10211857 BOX/PCB RJM505924-001V01 1 AL
X
36 10052232 KNOB/RTR M341402-1 1 AE C
N 37 10215187 SIDE BLOCK/LEFT RJM505781-001V01 1 AE C
N 38 10211863 RUBBER KEY RJM505783-001V01 1 AD C
N 39 10213956 PCB ASSY/CNA1 TK-RJM506271*001 1 BL C
VR401 69308726 POTENTIOMETER RK09K12C0D0
W
1 AI
X
D401-408 10171338 LED LT2P71-81-M1-S06 8 AA C
SW401-407 10047536 TACT SWITCH SKQNAED010 7 AA C
N 40 10213957 PCB ASSY/CNA2 TK-RJM506274*001 1 BA C
N CN402 10212787 HARNESS SCN-4P-52-M406 1 AC
X
J401,402 10171449 CONNECTOR JY-6360*04-070 2 AE C
N L401,402 10206672 COIL R2318-RB53856396NP 2 AA
X
41 69245260 BUTTON/POWER M340318-1 1 AA C
N 42 10215188 SIDE BLOCK/RIGHT RJM505782-001V01 1 AE C
43 34121827 POWER SWTICH SDDLD1-A2-D 1 AM C
N 44 10212697 HARNESS EH-2P-123-M406 1 AC
X
N 45 10214570 SIDE BRACKET/RIGHT RJM505896-001V01 1 AD
X
Notes: Q- Quantit
y
p
er uni
t
R- Ran
k

Casio PX-700 Specifications

General

Built-in Songs	60
Speakers	12cm x 2
Amplifier Output	8W + 8W
Power Consumption	18W
Polyphony (Maximum)	128
Digital Effects	Reverb (4 types), Chorus (4 types)
Transpose	±1 octave (–12 to +12 semitones)
Tuning	Yes (A4 = 415.5Hz to 465.9Hz)
Pedals	soft, sostenuto
Terminals	Headphone (Stereo standard jack) x 2
Power Supply	AC Adaptor (AD-A12150LW)
Included Accessories	music stand
Metronome	Beats: 0, 1, 2, 3, 4, 5 (Tempo range: quarter note = 30 to 255)
