— 7 —
5. Remove 11 screws.
6. Remove the PCB case.
7. Remove 3 connectors.
8. Remove 4 screws.
9. Remove the FPC and then the main PCB (M404-MDA1).
CN6
CN7
CN2

Other manuals for Casio PX-700

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio PX-700 and is the answer not in the manual?

Casio PX-700 Specifications

General IconGeneral
Built-in Songs60
Speakers12cm x 2
Amplifier Output8W + 8W
Power Consumption18W
Polyphony (Maximum)128
Digital EffectsReverb (4 types), Chorus (4 types)
Transpose±1 octave (–12 to +12 semitones)
TuningYes (A4 = 415.5Hz to 465.9Hz)
Pedalssoft, sostenuto
TerminalsHeadphone (Stereo standard jack) x 2
Power SupplyAC Adaptor (AD-A12150LW)
Included Accessoriesmusic stand
MetronomeBeats: 0, 1, 2, 3, 4, 5 (Tempo range: quarter note = 30 to 255)
