7.7 Expression (0BH)
Message Format: BnH 0BH vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when the pedal is operated by setting. (PX-S3100)
Sent when MIDI setting of Accomp Out set to ON and when automatic accompaniment is used.
(PX-S3100)
Receive Receipt changes the Expression value.
7.8 Damper Pedal (Sustain) (40H)
Message Format: BnH 40H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when a pedal that has a sustain function is operated.
Receive Receipt performs an operation equivalent to a sustain pedal operation.
Timbre Type Specific Operation This operation differs in accordance with the Timbre Type (see
“About the Timbre Type” in “8 Program Change”) setting.
• Timbre Type: Melody,Hex Layer
Sustain off/on control is performed in accordance with the value of the received message. For
information about the relationship between setting values and send/receive values, see the 13.1
Off/On Setting Value Table in IV Setting Values and Send/Receive Values .
• Timbre Type: Piano
Continuous control of the following is performed in accordance with the value of the received
message.
– Piano note decay rate
For information about the relationship between setting values and send/receive values, see 13.2
Sustain Pedal Setting Value Table in IV Setting Values and Send/Receive Values.
• Timbre Type: LM (Linear Morphing) Piano
Continuous control of the following is performed in accordance with the value of the received
message.
– Piano note decay rate
– Resonance characteristics and decay rate of Damper Resonance effect resonance note
see 13.2 Sustain Pedal Setting Value Table in IV Setting Values and Send/Receive Values.
• Timbre Type: Drum
The received message does not affect sound source op eration.
9
