— 123 —
1
QT-6600C
2
QT-6600B
3
QT-6600BD
123
N Item Code No. Parts Name Specification
Price
Code
Rank
Q'ty
RM45-RM52,RM55,RM58,
RM61,RM64,RM133,
RM160-RM162
REGISTOR ARRAY WA06X000PTL 16 16 16
RM54,RM57,RM60,RM63,
RM159
REGISTOR ARRAY WA06X510JTL 5 5 5
RM56,RM59,RM70,RM71,
RM73,RM74,RM78-RM81,
RM84-RM87,
RM134-RM140
REGISTOR ARRAY WA06X330JTL 21 21 21
C1
-
C3
,
C
5-
C10
,
C13
-
C22
,
C24-C35,C40,C41,
C44-C48,C50,C52-C55,
C57-C59,C61,C63,
C65-C75,C81-C83,
C88-C96,C98-C104,
C106-C113,C115-C124,
C129-C144,C148,
C150-C155,C157,C158,
C163,C166,C168-C170,
C172-C179,C188-C190,
C199,C201-C204,C206,
C207,C215-C217,C224,
C
CAPACITOR/CHIP 0402F104Z160CT 162 162 162
C4,C49,C51,C56,C60,
C62,C64,C76,C87,C186,
C206,C274,C282,C307
CAPACITOR/CHIP 0603B102K500CT 14 14 14
C11,C12
CAPACITOR/CHIP 0603N1R0J500LT 2 2 2
C23,C86,C146,C161,
C164,C177,C181,C275,
C279,C281,C287,C303
CAPACITOR/CHIP 0603B103K500CT 12 12 12
C36,C37,C42,C43,
C77-C80,C97,C105,
C114,C123,C145,C162,
C165,C171,C194,C208,
C263,C264,C271,C272,
C278
,
C297
CAPACITOR/CHIP 1206X106K100CT 24 24 24
C38,C39,C127,C128,
C159,C160
CAPACITOR/CHIP 0603N180J500LT 6 6 6
C84,C149,C156,C180,
C183,C187,C198,C205,
C246,C258,C283,C324,
C327-C331
CAPACITOR/CHIP RE3-16V101ME3# 17 17 17
C85
CAPACITOR/CHIP RE3-50V330ME3# 1 1 1
C125,C192,C200,C261,
C266,C268,C315
CAPACITOR/CHIP 0805B105K160CT 8 8 8
C126,C191,C193,
C195-C197,C209-C214,
C218-C223,C225-C230,
C234-C239,C248,
C295
,
C296
,
C299
CAPACITOR/CHIP 0603B104K250CT 34 34 34
C167,C244,C251-C257,
C270,C285,C301,C302,
C312,C318-323
CAPACITOR/CHIP 0603N101J500LT 19 19 19
C182,C276
CAPACITOR/CHIP 0603B223K250CT 2 2 2
C184,C185
CAPACITOR/CHIP 0603B682J500CT 2 2 2
C262,C269,C273,C277,
C289,C293
CAPACITOR/CHIP 1206X226K6R3CT 6 6 6
C265
CAPACITOR/CHIP 0603N561J500LT 1 1 1
