Casio QT-6600 Service Manual

— 126 —
1
QT-6600C
2
QT-6600B
3
QT-6600BD
123
Specification
Price
Code
Rank
Q'ty
N Item Code No. Parts Name
42
10315505 CABLE SUB ASSY/LVDS RJE502817*001V01 1 1 1 BN C
43
10323591 POWER-SW-ASSY RJE502826*001V01 1 1 1 BH
A
44
10315507 HOLDER/BAT RJE502789-001V01 1 1 1
A
KC
45
10315536 CABLE SUB ASSY/DRW RJE502844*001V01 2 2 2
A
VC
46
10078854 JOINER/FFC A-E27 E441341-1 1 1 1
A
EC
47
10320743 CABLE SUB ASSY/TP RJE502847*001V02 1 1 1
A
IC
48
10320742 CABLE SUB ASSY/INV1 RJE502846*001V02 1 1 1
A
IC
49
10319153 CABLE SUB ASSY/SOUND RJE502880*001V01 1 1 1
A
GC
50
10320792 CABLE SUB ASSY/FG RJE502700*001V02 1 1 1
A
HC
51
10315488 CABLE SUB ASSY/MC
R
RJE502849*001V01 1 1 1
A
QC
52
TAPE/DOUBLE RJE503028-1 4 4 4
62
10322434 BATTERY ASS
Y
TK-RJE502843*001 1 1 1
A
S5
SCREW S-BDMA-3X5Z3 12 12 12
S9
SCREW S-BDMA-3X8Z3 7 7 7
S10
SCREW S-PASWMA-3X5Z3 4 4 4
55600368 TIE/CABLE T-18S 2 2 2 AA X
6. B-CASE ASSY BLOC
K
53
10315511 CASE/REAR RJE502769-001V01 1 1 1 CJ C
54
10315512 CHASSIS/HNG RJE502775-001V01 1 1 1 DE
X
55
10315513 COVER/MCR E830 RJE502790-001V01 1 1 1
A
HC
56,57
10322435 SPEAKER ASS
Y
RJE502842*001 1 1 1
A
UC
58
10315515 CUSHION/SP RJE502806-001V01 3 3 3
AA
C
59
10315517 PLATE/R-DP RJE502777-001V01 1 1 1 BU C
60
10316800 TAPE/HIMELON RJE502798-001V01 1 1 1
A
CC
S7
SCREW S-BDPT-3X8Z3 1 1 1
S9
SCREW S-BDMA-3X8Z3 2 2 2
S11
SCREW S-WBPT-3X6Z3 3 3 3
S12
SCREW S-BDPT-4X10Z3 4 4 4
WASHER W-6X11.5X0.8Z3 3 3 3
7. OTHER
61
10322436 STAND ASS
Y
RJE502722*002V01 1 1 1 DH C
10315551 ADAPTOR/AC SO1330A 1 1 1 DG A
