I-4
System Installation
1. System installation
In this chapter shows how to install QT-6600 systems and peripherals.
1-1. How to load IPL (Initial Program Loading)
Normally, IPL is not necessary since the terminal has efficient programmable options to
meet your circumstances.
In some cases, you need to change the application program to meet your requirements, the
IPL is necessary to download the application program to the terminal.
To load IPL, there are two methods:
1) From CF card to a terminal
2) Remote IPL via Internet
1-1-1. From CF card to a terminal
1. Insert the CF card to the CF card slot of the target terminal.
2. Power on the terminal with pressing the INIT switch. (IPL
start)
3. After IPL completion, continue to the initialize operation.
CF card
IPL source
IPL target
IPL Data
CF card slot is located
on the leftside of the terminal.
C
C
CF slot
INIT Sw
To Next Page
