— 32 —
13-3. Third screw
13-4. Fourth screw
14. Remove the cable (D PCB/ CN300).
15. Remove the cable (BL PCB/ CN900).
16-1. Disconnect three cables (D PCB).
CN706
16-2. CN705
16-3. CN200
17-1. Disconnect four wires (D PCB).
