Casio SE-S10 Service Manual

— 43 —
1 SE-S10MB
2 SE-S10MBUA
3 SE-S10MBUG
4 SE-S10MBUK
5 SE-S10MD
6 SE-S10SB
7 SE-S10SBUA
8 SE-S10SBUG
9 SE-S10SBUK
10 SE-S10T
11 PCR-T280
12 PCR-T280L
13 PCR-T290L
12345678910111213
1. FINAL ASSY
N
1
10345779 BOARD/DISPLAY RJE502996-005V03 1 1 C
N
1
10345780 BOARD/DISPLAY RJE502996-006V03 1111111111 C
N
1
10345782 BOARD/DISPLAY RJE502996-007V03 1 C
N
2
10347379 ARRAY/KEY RJE503262-001V01 1111111111111 C
3
10326707 COVER/BATTERY RJE500211-001V03 1111111111111 C
4
10349665 PULLY/WIND RJE501880-001V04 1111111111111 A
5
10285007 SPOOL/PAPER RJE502545-001V01 1111111111111 A
N
6
10347360 COVER/PRINTER RJE502997-003V01 1111111111111 C
7
10325056 SUB ASSY/TRAY RJE503008-001V01 111111 C
8
10254924 SUBASSY/KEY SET RJE500074*002V03 1111111111 C
N
9
10325043 SUBASSY/KEY SET RJE503007*002V01 1 1 1 C
S1
SCREW S-BDST-3X8ZC 1111111111111
2. U-CASE ASSY
N
10
10347303 PCB ASSY/E276-1 RJE503222*001V01 1 A
N
10
10347342 PCB ASSY/E276-1 RJE503222*002V01 1 1 A
N
10
10347311 PCB ASSY/E276-1 RJE503222*004V01 1111111111 A
N
11
10347316 PCB ASSY/E276-E2 RJE503224*002V01 1111111111111 A
N
12
10347351 CASE/UPPER RJE503254-001V01 1111111111111 C
13
63224499 SPRING/BATTERY A42606-1 1111111111111 C
14
10294939 SPRING/BATTERY RJE502620-001V01 1111111111111 C
15
10294940 SPRING/BATTERY RJE502622-001V01 1111111111111 C
N
16
10350060 SUB ASSY/BAT-CABLE RJE503227*001V02 1111111111111 C
N
17
10347321 MOUNT/MOTOR RJE503259-001V01 1111111111111 C
N
18
10240554 ASSY/MOTOR E441295*003V01 1111111111111 A
N
19
10347330 MOUNT/PCB RJE503260-002V01 1111111111111 C
N
20
10347323 SUPPORT/PCB RJE503267-001V01 1111111111111 C
21
10349673 PLATE/FG RJE503298-001V01 1111111111111 C
22
10236317 CUTTER/PAPER E441364-001V02 1111111111111 C
N
23
10347345 MOUNT/PRINTER RJE503266-001V01 1111111111111 C
N
24
10347346 ARM/EJECT RJE503261-001V01 1111111111111 C
25
10327860 SW ASSY/MODE-KEY E341249*004V01 1111111111111 C
26
10142488 ROLLER/P RJE500850-001V01 1111111111111 B
27
10142489 ROLLER/P/D RJE500851-001V01 1111111111111 B
N
28
10240926 FFC E441341-010V01 1111111111111 C
N
29
10347352 ARM/PLATEN RJE503264-001V01 1111111111111 C
30
10226189 PRINTER LTPZ225B-C192-E 1111111111111 A
N
31
10347329 HOLDER/POWER RJE503288-001V01 1111111111111 C
N
32
10347349 UNIT/POWER SO1258A 1111111111111 C
N
33
CORD/POWER E (*B) 1 1 1 1 C
N
33
CORD/POWER U (*C, L) 1 1 1 C
N
33
10240096 CORD/POWER AR1CSEX270-UKLF 1 1 1 C
N
33
10240097 CORD/POWER AR1CSEX270-SAA-ALF 1 1 C
N
33
CORD/POWER U (*P) 1 C
S1
SCREW S-BDST-3X8ZC 7777777777777
S2
SCREW S-BDPT-3X8Z3 13 13 13 13 13 13 13 13 13 13 13 13 13
S3
SCREW S-PAMA-2.5X4Z3 13 13 13 13 13 13 13 13 13 13 13 13 13
Specification
Price
Code
R
Quantity
N Item Part No. Part Name

Casio SE-S10 Specifications

General

Types of payment	Cash
Number of clerks/departments	20
Number of Price Look-Up codes (PLUs)	500 PLUs
Supported paper width	57.5 mm
Backlight	Yes
Display digits	8 digits
Display number of lines	1 lines
Dimensions (WxDxH)	330 x 360 x 203 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	120/230 V
Power consumption	100 mA

Weight and Dimensions

Weight	4100 g
