Casio SE-S10 Service Manual

— 46 —
1 DL-1334
2 DL-1843
12
1 55000878 ROLLER/DELRIN DR-19B2 4 4 AF B
2 10201068 LOCK/SPRING RJE500007-001V02 1 1 AF C
3 10194207 SPRING/PRESS E412137-001V02 1 1 AA C
4 10167366 RUBBER/PAD RJE501204-001V01 5 5 AD C
5 10080189 SUB ASSY/SOLENOID E341255*2 1 1 AV B
6 10259120 LEVER/HOOK RJE502182*001V01 1 1 C
7 10260417 AXIS/LEVER HOOK RJE502184-001V01 1 1 AA C
8 10267909 SPRING/PLUNGER RJE502245-001V01 1 1 AA C
9 10317352 CASE/MAIN RJE500670-003V05 1 1 BY B
10 10324884 PLATE/FRONT RJE502970-001V01 1 1 BI B
11 10298553 PLATE/PARTITION RJE500214-002V03 3 2 AB C
12 10231349 SUB ASSY/BILL HOLDER RJE501337*002V03 1 AR X
12 10231347 SUB ASSY/BILL HOLDER RJE501337*001V03 1 AQ X
13 10276626 SPRING/BILL HOLDER E441357-001V03 4 3 AA A
14 10238184 RIVETS/COLD HEADED T-CRTP-5X26Z3 1 1 AA X
15 55801452 CS FIX CSTW-5 1 1 AA X
16 10120527 SUB ASSY/CAM LOCK CL-16C 1 1 BA C
17 10298558 CASE/COIN RJE500212-002V04 1 1 AO C
18 10298552 SEPARATER/COIN RJE500213-002V03 4 4 AA C
19 10317357 CASE/BILL COIN RJE500671-005V04 1 1 BL X
20 10324882 COVER/TOP RJE502986-001V01 1 1
BP X
W1 10080122 WASHER 11.5X6.5XT0.8 2 2
N1 NUT 6 ZMC-3 2 2
N2 NUT N-HXT2-6Z3 2 2
S1 SCREW 3X8 ZMC-3,, 4 4
S2 SCREW S-WBPT-4X25Z3 1 1
S3 SCREW S-PAPT-3X22Z3 2 2
S4 SCREW S-PAB0-3X8Z3 3 3
S5 SCREW S-BDPT-3X6Z3 3 3
N Item Part No. Part Name
Price
Code
R
QUANTITY
Descriptions

Casio SE-S10 Specifications

General

Types of payment	Cash
Number of clerks/departments	20
Number of Price Look-Up codes (PLUs)	500 PLUs
Supported paper width	57.5 mm
Backlight	Yes
Display digits	8 digits
Display number of lines	1 lines
Dimensions (WxDxH)	330 x 360 x 203 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	120/230 V
Power consumption	100 mA

Weight and Dimensions

Weight	4100 g
