— 10 —
4. EXPLODED VIEW: MODULE QW-2634
9 (1008 3364)
6 (1006 5657)
(CTL1616)
8 (7218 0438)
19 (7230 0644)
16 (1008 2133)
11 (1008 2135)
7 (7231 1913)
1 (1013 1512)
Casing parts:
Dial ass'y with solar cell
20 (1008 4578)
12 (1006 5664)
14 (1009 9862)
10 (1008 2102)
11 (1008 2135)
15 (1008 2132)
18 (1008 2134)
3 (7640 7246)
PCB Ass'y
Casing parts: Spacer
2 (1008 9590)
17 (7230 0616)
