Casio WK-240 Service Manual & Parts Catalogue

1: WK-240_DI
2: WK-240_EU
3: WK-240_UK
4: WK-240_US
WK-240
– 33 –
1234
N Item Code No. Parts Name Specification
Q'ty
R Remarks
Q2,Q3,Q5,Q6,Q9
10399706 TRANSISTOR DSC500100L 5555X
Q1
10217742 TRANSISTOR KTA1270-Y-AT/P 1111X
Q4
10206675 TRANSISTOR KTA1273-Y-AT/P 1111X
3
10308432 LED SLR343BD2T3F 2222X
4
10123033 REFLECTOR RJM502534-001V01 1111X
5
10122917 BACK LIGHT PLATE RJM502475-001V01 1111X
6
10122970 FILM RJM502473-001V01 1111X
7
10081190 TOP PIECE RJM501982-001V01 1111X
8
10270485 SPONGE/8X75 M441167-001 2222X
Keyboard PCB
9 10399944 PCB UNIT/KYA TK-RJM508870*003 1111CKYA1/KYA2
D801-D952 23153132 DIODE 1SS133T-77 152 152 152 152 X
Panel Unit
N 10 10480920 DISPLAY PLATE RJM511158-004V01 1111X
11 10399707 KNOB/ROTARY M341109-012V01 1111C
N 12 10480924 CASE/PANEL RJM511092-004V03 1111X
13 10401543 SHEET/V-ZERO RJM511424-001V01 1111X
14 10399732 RUBBER BUTTON/A RJM511119-001V01 1111X
N 15 10480921 RUBBER BUTTON/B RJM511120-003V01 1111X
16 10399743 RUBBER BUTTON/C RJM511133-001V01 1111X
17 10399736 RUBBER BUTTON/D RJM511122-001V01 1111X
18 10399738 RUBBER BUTTON/E RJM511123-001V01 2222X
19 10399741 RUBBER BUTTON/P RJM511125-001V01 1111X
20 10402782 LCD ZAS-TY012724DN00 1111X
21 10310620 RUBBER CONNECTOR/for LCD RJM505823-002V01 2222X

Casio WK-240 Specifications

General

Control type	Buttons
MIDI-keyboard number of keys	76 keys
Metronome	Yes
Product color	Black, Silver
Sound effects	Chorus, Reverberation
Sound effects quantity	180
Maximum polyphony (notes)	48
Music memory capacity (songs)	10
Interface	USB
Headphone outputs	1
Display type	LCD
Power source type	AC, Battery, DC
Number of batteries supported	6

Weight and Dimensions

Depth	385 mm
Width	1161 mm
Height	134 mm
Weight	6900 g
