Casio WK-240 Service Manual & Parts Catalogue

WK-240
– 2 –
MIDI 16 multi-timbre received, GM Level 1 standard
Musical Information Function Tone, Rhythm, Song Bank numbers and names, staff notation,
fi ngering, pedal operation, tempo, measure and beat number,
chord name, etc.
Inputs/Outputs
USB port
Sustain/Assignable jack
Phones/Output jack
Audio In jack
Mic In/Sampling jack
TYPE B
Standard jack (sustain, sostenuto, soft, rhythm)
Stereo standard jack
Output Impedance: 140 Ω, Output Voltage: 4.5 V (RMS) MAX
Stereo mini jack
Input Impedance: 9 kΩ, Input Sensitivity: 200 mV
Standard jack (connect a dynamic microphone only)
Input Impedance: 3 kΩ, Input Sensitivity: 10 mV
Power Jack DC 9.5 V
Power Supply
Batteries
Battery Life
AC Adaptor
Auto Power Off
2-way
6 D-size zinc-carbon batteries or alkaline batteries
Approximately 5 hours continuous operation on zinc-carbon batteries
AD-E95100L
• The AC adaptor can be used safely in areas up to 4,000 meters
above sea level.
Approximately 6 minutes (during battery operation) or 30 minutes
(during AC adaptor operation) without any operation, Auto Power Off
can be disabled.
Speakers 12 cm × 2 (Output: 2.5 W + 2.5 W)
Power Consumption 9.5 V
=
7.7 W
Dimensions 116.1 × 38.5 × 13.4 cm (45
3
/
4
× 15
3
/
16
× 5
1
/
4
inch)
Weight Approximately 6.9 kg (15.2 lbs) (without batteries)
* This data is stored in a shared memory area with a total capacity of approximately 320 Kbytes (1 Kbyte =
1,024 bytes).

Casio WK-240 Specifications

General

Control type	Buttons
MIDI-keyboard number of keys	76 keys
Metronome	Yes
Product color	Black, Silver
Sound effects	Chorus, Reverberation
Sound effects quantity	180
Maximum polyphony (notes)	48
Music memory capacity (songs)	10
Interface	USB
Headphone outputs	1
Display type	LCD
Power source type	AC, Battery, DC
Number of batteries supported	6

Weight and Dimensions

Depth	385 mm
Width	1161 mm
Height	134 mm
Weight	6900 g
