E-13
Rear Panel
• WK-3800
i
SUSTAIN/ASSIGNABLE JACK terminal
j
LINE OUT R, LINE OUT L/MONO terminal
k
DC 12V terminal
i ki j k
• WK-3300
i
SUSTAIN/ASSIGNABLE JACK terminal
k
DC 12V terminal
General Guide
NOTE
• Display examples shown in this User’s Guide are intended for illustrative purposes only. The actual text and values that
appear on the display may differ from the examples shown in this User’s Guide.
• Due to LCD element characteristics, display contrast changes depending on the angle from which you view it. The initial
default contrast setting is one that allows easy viewing for a musician seated directly in front of the display. You can also
adjust the contrast to the level that suits your particular needs. For more information, see page E-74.
l m
• WK-3300/WK-3800
l
SD memory card slot
m
USB port
m
USB port
Front Panel
• WK-8000
l
SD memory card slot
• WK-8000
i
SUSTAIN/ASSIGNABLE JACK terminal
j
LINE OUT R, LINE OUT L/MONO terminal
k
DC 12V terminal
i j k
m
l
