— 28 —
N Item Code No. Part Name Specification Q
Price
Code
R Remarks
Main PCB MA1M
N 1 1012 8736 PCB ASSY/MA1M TK-RJM502981*002 1 DW A
IC2 1012 2526 LSI LH28F160BJHE-BTL90 1 BD B
N IC3 1012 9320 LSI R27V6402G01CTNZ04 1 BQ B
IC4 1012 6397 LSI CY62128VLL-70ZAIT 1 AX B
IC5 2105 6665 IC UPD63200GS-E1 1 AX B
IC6 1012 1554 LSI D442000AGUBB859JE3 1 BG B
IC7 2105 4158 IC TA75S393F(TE85L) 1 AC B
IC8 6932 0063 IC R1151N001C-TR 1 AF B
IC9 6930 9981 IC TC74VHCT08AF(EL) 1 AC B
IC10 1012 3005 IC TC7WH123FU(TE12L) 1 AF B
IC11,14 1008 1273 IC TC7SH00FU(TE85L) 2 AB B
IC12 1012 3002 IC TC74VHC174FT(EL) 1 AD B
IC13 1012 1552 IC ADC08832IMX 1 AR B
IC15 1005 4502 LSI UPD914AGM-3ED 1 CK B
IC16 1012 2999 IC TC74LCX00FT(EL) 1 AB B
IC17 2105 6576 IC TC74LCX245FT(EL) 1 AF B
IC18 2105 6621 IC TC74LCX138FT(EL) 1 AF B
IC20 2012 5987 LSI TC190C020AF-001 1 BC B
IC29 2105 6473 IC TC7WH125FU(TE12L) 1 AF B
IC30 6930 9994 IC TC7SH32FU(TE85L) 1 AB B
IC31 1012 3000 IC TC74VHC125FT(EL) 1 AD B
IC33 6930 9995 IC TC7SZ08FU(TE85L) 1 AD B
Q1,3,8,10 2252 1169 TRANSISTOR 2SC4081T106S 4 AA C
Q2 2259 2757 TRANSISTOR 2SD2150-T100R 1 AB C
Q5 1001 5566 TRANSISTOR 2SB1181TLR 1 AC C
Q7,Q9 2250 1169 TRANSISTOR 2SA1576AT106S 2 AA C
D1 1012 3121 DIODE UDZSTE-174.3B 1 AA C
D2 2390 2058 DIODE 1SR154-400TE25 1 AB C
D5,7 2390 1820 DIODE 1SS355TE-17 2 AA C
D6,8 2775 2079 DIODE DA227-TL 2 AA C
L2,3 1012 2963 COIL BLM21AG102SN1D 2 AC C
L5,6,7,9,
10,11,12, 1009 5204 COIL BLM18AG102SN1D 21 AA C
14-26,29
CN1 1006 2669 CONNECTOR CN015R-3013-0 1 AT C
X1 1005 9360 OSCILLATOR/CRYSTAL SMD-49-16.384M 1 AI C
N L13 3045 0028 COIL BK1608HS601-T 1 AA C
Sub PCB MA2M
N 2 1012 8737 PCB ASSY/MA2-3M TK-RJM502983*003 1 CR B
IC201 6932 0061 IC PQ1CG21H2FZ 1 AO B
IC202,203, 204 2121 0072 IC NJM2068DD 3 AD B
IC205 1006 2671 IC LA4636 1 AV B
Q201,203,
204,205,207, 2250 1627 TRANSISTOR 2SC1740STPS 7 AA C
209,210
Q202 2250 1591 TRANSISTOR 2SB1237TV2R 1 AB C
D201,202 1009 4579 DIODE 1N5822 2 AC C
D203,210,
212,213
D205 1011 5969 DIODE DZ5.6BSBTP 1 AA C
D206 2390 1463 DIODE SB20-03B 1 AD C
D209 2114 1421 PHOTO COUPLER PC900V 1 AK C
CN201 3501 4816 JACK/DIN YKF51-5051 1 AH C
J201 3501 5012 JACK/DC HEC2305-01-920 1 AC C
J204 3612 0789 JACK YKB21-5010 1 AC C
Notes: N- New parts R-A: Essential
Q- Quantity used per unit B: Stock recommended
R- Rank C: Others
X: No stock recommended
AA C2315 3132 DIODE 1SS133T-77 4
To Next Page
