Casio WK-3500 - Console and Keyboard Parts List

— 29 —
N Item Code No. Part Name Specification Q
Price
Code
R Remarks
L201,202,
204,205,206, 1005 6228 COIL R2318-RB53-856397 8 AB C
207,208,209
L203 1007 1755 COIL R187-860400 1 AF C
L210 1005 7360 COIL R2318-RB53-856396 1 BB C
Console PCB CN1M~CN7M
3 1012 3295 PCB ASSY/CN1M TK-RJM502984*001 1 BT B
4 1012 3296 PCB ASSY/CN2M TK-RJM502985*001 1 BN B
5 1012 3297 PCB ASSY/CN3M TK-RJM502986*001 1 BM B
6 1012 3298 PCB ASSY/CN4M TK-RJM502987*001 1 BN B
7 1012 3299 PCB ASSY/CN5M TK-RJM502988*001 1 BN B
8 1012 3300 PCB ASSY/CN6M TK-RJM502989*001 1 BJ B
9 1012 3301 PCB ASSY/CN7M TK-RJM502990*001 1 BJ B
IC301 6932 4293 LSI UPD65881GK-062-9ET 1 AT B CN1M
Q301,304,305 1002 5037 TRANSISTOR 2SA933STPS 3 AA C CN1M
D305-322 2315 3132 DIODE 1SS133T-77 18 AA C CN1M
D302-304 1012 2219 LED 1154GD-B5/9-90 3 AD C CN1M
D301 1012 3008 LED 1154GD-B5/8-90 1 AD C CN1M
L301,302 6932 1437 FERRITE BEAD BB36-851665 1 AA C CN1M
X301 2529 2032 OSCILLATOR/CERAMIC CSB1000J 1 AC C CN1M
VR301 1012 3103 VARIABLE RESISTOR RK09K12C0D1B 1 AH C CN2M
J301 3612 0665 JACK/PHONE JYB21-5006 1 AG C CN3M
D325 1012 6405 LED SDPB3DD0A100DEFGHI 2 AH C CN4M
D324 1012 6405 LED SDPB3DD0A100DEFGHI 2 AH C CN5M
D328,329 1012 3006 LED 1154GD-B5/4.5-90 1 AD C CN6M
D323 1012 3008 LED 1154GD-B5/8-90 1 AD C CN7M
BL assy
10 1012 3292 BACK LIGHT ASSY TK-RJM503021*001 1 BW B
10-1 1012 3033 REFLECTOR RJM502534-001V01 1 AD C
10-2 1012 3302 PCB ASSY/LCD1M TK-RJM502995*001 1 BO B
IC401 1000 6502 LSI ML9040-B02GA 1 AU B
IC402 1012 2996 IC TC74HCT08AF(EL) 1 AB B
Key board assy
11 6922 2720 KEY SET/LT WHITE M312118*1 5 AP C
12 6923 7900 KEY SET/LT76R WHITE M340231*1 1 AO C
13 6923 7910 KEY SET/LT76L WHITE M340230*1 1 AO C
14 6906 8482 KEY SET/LS BLACK M140369B-3 2 AH C
15 1002 5058 KEY SET/LSK-8P BLACK M140369-8 1 AH C
16 1002 5059 KEY SET/LSK-3P BLACK M140369-7 1 AN C
17 1002 5055 RUBBER/CONTACT CB M241297-1 5 AJ C
18 1002 5054 RUBBER/CONTACT EB M241298-1 1 AH C
19 1002 5060 RUBBER/CONTACT CG M241299-1 1 AH C
20 1012 3289 PCB ASSY/KY1-2M TK-RJM503000*001 1 BT B
D801~D952 2315 3132 DIODE 1SS133T-77 152 AA C
Case Unit
21 1002 5069 COVER/BATTERY TK-M341288*1 1 AV C
22 1012 8668 PLATE/DISPLAY RJM502476-002V01 1 AP C
23 1012 3034 KNOB/ROTARY M341109-002V01 1 AC C
24 1013 0442 SPEAKER S12JA10A
2 BG C
25 1013 0441 SPEAKER S05JH54A
2 AS C
26 1012 6412 LCD WK-TZB637-TH-A 1 BV C
27 1012 2917 PLATE/BACK LIGHT RJM502475-001V01 1 AP X
28 1012 2970 FILM RJM502473-001V01 1 AA X
Notes: N- New parts R-A: Essential
Q- Quantity used per unit B: Stock recommended
R- Rank C: Others
X: No stock recommended
