9
* This serial port is for connecting a separately available special cable (YK-5) to control the projector
from a computer.
Important!
Be sure to use alkaline batteries only.
Replacing Remote Controller Batteries
Open the battery cover on the back of the remote controller, replace the old batteries with new ones,
and then close the battery cover.
Back Terminals
Loading Remote Controller Batteries
*
Caution
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
1.
Open the battery cover on the back
of the remote controller.
2.
Load two new batteries into the
case, making sure that their positive
(+) and negative (–) ends are facing
correctly.
3.
Close the battery cover on the back of the remote controller.
Serial port*
COMPUTER terminal
USB port
(XJ-A146/XJ-A246/XJ-A256 only)
Power connector
Anti-theft lock hole
Intake vents
AV terminal
HDMI port
Speaker
Remote control signal receiver
To Next Page
