Casio XJ-A256 Function Guide

39
MobiShow is client software by AWIND that makes it possible to send data wirelessly from various
types of mobile terminals to the projector for projection. MobiShow can be used to send photographs
and presentation files to the projector and project them.
To project from MobiShow
1. Using the procedure under “To switch between Default SSIDs” (page 30), select
casiolpj_mobishow1, casiolpj_mobishow2, or casiolpj_mobishow3 as the SSID.
z These are default SSIDs for the first connection with MobiShow. The following are the initial
default settings of the security protocol and pass phrase.
2. On the mobile terminal, start up MobiShow, log in to the projector, and then
perform the projection operation.
z For details about MobiShow operations, see the user documentation that comes with
MobiShow.
Important!
Once you use the above procedure to establish a wireless LAN connection between the mobile
terminal and projector, it is recommended that you create a new SSID and configure a pass
phrase that is different from the initial default. After that, use the SSID you create to establish a
wireless LAN connection. To create a new SSID, perform the following steps while there is a
wireless LAN connection between the mobile terminal and projector.
To create a projector’s new SSID by using a mobile terminal
1. Look up the projector’s IP address.
z Perform the following steps to look up the projector’s current IP address.
1. Press the [MENU] key to display the setup menu.
2. Use the [T] and [S] keys to move the highlighting to “Wired LAN settings” and then press
the [ENTER] key.
3. Use the [T] and [S] keys to move the highlighting to “Wired LAN info” and then press the
[ENTER] key.
2. On the mobile terminal, start up your web browser and access the IP address
that you looked up in step 1.
z If the projector’s current IP address is 192.168.100.10, for example, you would access:
“http://192.168.100.10”.
z This displays the top page of the projector’s System Admin page.
3. Click “System Admin”. On the password input screen that appears, enter the
password.
z The initial default password is “admin”.
Projecting from a Terminal with MobiShow Installed
SSID Security Setting Initial Default Pass Phrase
casiolpj_mobishow1
WPA-PSK AES
casiolpj1
casiolpj_mobishow2 casiolpj2
casiolpj_mobishow3 casiolpj3

Casio XJ-A256 Specifications

General

Matrix size	0.65 \
Number of colors	16.78 million colors
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	18 - 300 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	±30 °
Aspect ratio	16:10
RS-232 ports	1
Offset	84 %
Throw ratio	1.15 - 2.3:1
Optical zoom	2 x
Zoom capability	Yes
Focal length range	- mm
Service life of light source	20000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1280 x 800 (WXGA)
RMS rated power	1 W
USB connector type	USB Type-A
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Wi-Fi standards	802.11b, 802.11g
Noise level	35 dB
Noise level (economic mode)	29 dB
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, ITA, JPN, KOR, SWE
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	110 W
Power consumption (typical)	210 W
Power consumption (PowerSave)	0.4 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, Composite, VGA

Weight and Dimensions

Depth	210 mm
Width	297 mm
Height	43 mm
Weight	2300 g
