CASTLE, INC TSM-21 Bosch Motor Carriage Install Page 13 of 25
4 Final Installation and Adjustments
4.1 Motor Replacement
• Install the Bosch Model 1617 Router Motor in the carriage by slipping it through the carriage
and up into the U-bolt. Make sure it is seated at the top.
• Tighten with the bar knob.
• Plug in motor.
Note: Removing the Work Top will allow easier access to the router motor for cor-
rect placement.
• Install the Bosch PR20EVS Trimmer Motor in the carriage. Make sure it is seated correctly.
• Tighten with bar knob.
• Plug in motor.
4.2 Carriage Adjustments
• Adjust the carriage right or left with the set screws to position the carriage so that the router
bit is centered in the machine, using the hole for the drill as a reference point. The pilot hole
will be adjusted separately.
• Once the carriage is centered based on the location of the router bit, tighten the lock nuts on
the sets screws while holding the set screws in position with an Allen wrench.
• The drill is centered by adjusting the nut located below and to the front of the Drill Motor T-
Handle.
• Adjust the nut as needed to position the pilot hole bit in the center of the hole in the case,
and to the center of the pocket.
Note: Only tighten the nut as needed. Overtightening can reduce the ability to
move the bit in the opposite direction.
