3
Control Unit Mounting Base
Handlebar Post
Cable Connector
(Earlobe) Pulse Sensor
Sensor Clip
Pulse Sensor Plug
Handlebar Adjusting Lever
Cable Holder
7P Cable
Pedal
Crank
Control Unit
Handlebar
Saddle
Workload Shift Lever
Pedal resistance is adjusted in
8 grades
Seat Post
Spring Lock Pin
Rear Leg with level
adjusters
Pulse Sensor
Cable Clip
Earlobe Sensor
Handlebar Post
Fastening Screw
Front Leg with Casters
Plug
