13
Main Power ON/OFF Switch
ON/OFF Switch located at the center front
underside of the system.
Prophy Mode Auto Cycles
Automatically cycle between air polish and rinse
without pumping foot pedal. Choose short, medium
or long prophy cycle times. See section 9.8 for
more details.
Ultrasonic Power Level Control
Turn knob to select the ultrasonic power level for operation. Turning the knob clockwise
increases the distance the insert tip moves (stroke) without changing the frequency;
turning the knob counterclockwise decreases the distance the insert tip moves (stroke)
without changing the frequency.
The Blue Zone is an extended low-power range for improved patient comfort when
subgingivally scaling.
Rinse
Turn the ultrasonic power level control knob fully counterclockwise until a “click” is heard.
Rinse mode is for use during an ultrasonic scaling procedure when lavage is desired with
minimal cavitation.
Diagnostic
Display
See section
8.2 for more
details.
Rinse
Blue Zone
JET-Mate™
Handpiece
Accepts all
Cavitron
®
30K
™
Ultrasonic inserts
and Cavitron
JET Air Polishing
Inserts. Auto-
matically selects
air polishing or
scaling mode.
See section 8.3 for
more details.
Handpiece Holder
Securely holds the
system’s handpiece,
or cable connector
when handpiece is not
installed.
Tap-On
TM
Wireless Foot
Pedal
Eliminates the need to hold down
or pump foot pedal.
See section 8.6 for more details.
Powder Flow Control
Rotate clear Powder Flow
Control to adjust powder
flow rates. For minimum
powder flow turn control
clockwise to “L”. For
maximum flow turn to “H”.
