CONTROL PANEL “PC380-ST”
DESCRIPTIONS
4) Button with integrated twilight sensor to set
the intensity of the LED backlighting in a
“night”
5) On/off button (to turn on/off press for 2
seconds) at the start-up the display carries
out a functioning test and shows all symbols
(including unused symbols).
main
:
2) Button to switch the pump on and off.
situation (see also the “TWILIGHT” function).
3) light button; this light switches
automatically off when you start up the engine
Awning awning
(it depend on the 12V button).
If the relevant LED is green the control panel
is on, if it is red an alarm is on (batteries,
tanks, etc.).
1) 12V button (lights, 12V sockets electric
“SAT” and awning light).
, antenna
7) Button for the control of fresh water tank (in
%), for fresh water refilling function operation
(see “FRESH WATER TANK REFILLING”
function) and for the regolation of the
programmable parameters’ setting (see
SETTING).
6) “PROG” button for system (see
SETTING).
setting
8) Button for control of car and leisure batteries
voltage (in Volt) and for the regolation of the
programmable parameters’ setting (see
SETTING).
NOTE: The watch is supplied from the leisure
battery (B2). Should B2 be disconnected,
the watch is able to keep working, without
visualization, for about week 2 .
1 2 3 4
1
2 3
4
5 76
8
