13
Mounting your extractor
When the extractor is to be installed
above an electric hob, the minimum
distance between the hob and extractor
must exceed 600mm (650mm is
recommended).
When the extractor is to be installed
above a gas hob, the minimum distance
between the hob and extractor
must exceed 700mm (750mm is
recommended).
If the instructions provided with your
gas hob state that the required distance
between the hob and extractor must be
greater than 700mm, then that is the
distance that should be observed; this
is a legal requirement and may lead to
your hob being disconnected from the
gas supply and the installation being
reported to RIDDOR (The height should
be measured from the top of the burners).
Fig. 5
Fig. 4
ECH61/
ECH71
ECH91/
ECH101
A 55 55
B 210 210
C 400 400
D 203 303
E 75 75
F 65 65
Gas: 750mm recommended.
Electric: 650mm recommended.
