30
Figures 14 and 15 on page 31 show the recommended installations of
our dishwashers. The set-ups in these figures should be mimicked
wherever possible to help to ensure the best performance of the ap-
pliance. Please carry out the below checks/measures before, dur-
ing and after installation.
Drain hose
• This can be connected to a water drain or to a sink outlet spigot.
Where the hose is to be connected to a spigot, ensure that the
spigot is cut/opened (if required) before attaching the hose.
A circlip can be used to secure this connection. Observe the
150mm minimum height distance between the spigot and drain
hose support as per fig. 15.
• The drain hose support (fig. 16) must be secured at a minimum of
60cm and a maximum of 110cm from the floor and must be higher
than the sink waste.
• Should be no longer than 4m in order to ensure good perfor-
mance.
• Must be free from kinks, debris or damage. It is important that
this is checked before and after installation.
Inlet hose
• This must be free from kinks, debris or damage. This must be
checked before and after installation.
• Should have a bend radius of 200mm minimum to ensure the
proper flow of water to the appliance.
• Ensure the supply to the hose (water valve) is turned on.
