CD42 Pipeline Pig Location & Tracking System
Page 28
Once the printer is connected, powered on, and online the operator can proceed with printing any
previously recorded PICtures. Using the same steps described earlier in „Viewing a Recorded File”,
the operator selects a file to be printed by placing the highlight bar on the appropriate file.
Single Recording File Image
Once the desired file is selected, press the Print button ( Figure 35):
Figure 35 Print Icon
At this time an option screen is displayed which gives the operator two options: print a single
File Image from the file list, or print a list of all file recordings. To print a File Image, press the
File Image button.
If the printer is online and connected, it will immediately begin printing the PICture file image.
If the printer is not online, the operator will instead receive an error message. Press any button
to clear the error message and return to the File Submenu screen (see Figure 36). Correct the
printer error and try again.
