INSTALLING THE A22 PC BOARD
Install the 5 fasteners (PCB holder) supplied respectively to the box holes identied in red in the following
picture. Install the A22 PCB by aligning the fasteners with the corresponding PCB holes and pressing rmly to
secure the PCB in place.
