3] PACKAGE CONTENTS
This chapter details how to install and setup the ATRIUM A22 .
The A22 contains:
• One A22 module in its cabinet with connection diagram label
• AC power cord
• Metal Box kit (See below)
• Installation kit (See below)
Metal Box
Kit
Wall Switch
and a white
wire (115mm)
3 wires for
tamper switch
(2 x 360mm
and
1 x 165mm)
Bolts and Nuts
Wall Switch
Spacer
Door Switch
and 2 white
wires
(350mm)
Door Switch
Support
Metal box
screw for door
enclosure
Metal box
lock and key
1 3 2 each 1 1 1 4 1
Installation
Kit
Red and black
wires, for
backup battery
(400mm)
1K Resistor 2.2K Resistor
Diode 1N4007
for DC door
strikes or
maglocks
Varistor for AC
door strikes or
maglocks
Fastener
(PCB Holder)
1 pair 22 10 2 2 7
If any item is missing, please notify your distributor immediately.
