3] MOUNTING KIT
2] NOTES AND RECOMMENDATIONS
CABLE
- The distance between the KCIN
and the remote electronic can not exceed
more than 10 meters.
- Make sure that the cable is not near
by a high voltage cable (ex: 230 V AC).
Recommended cable between
The KCIN and the remote electronic
2-pair cables (4 wires) SYT1 8/10
ths
.
Recommended power supplies
suitable for the KCIN
- ARD12 (230V input)
- BS60 (230V input)
Mounting recommendations
Mount the keypad on a fl at surface to avoid
any vandalism and to insure the best mounting.
Security advice
- For security reasons, change
the factory default master code.
- When selecting a master code and user code
avoid simple codes (example : 3 4 5 6 7).
Back EMF protection
To secure the system from back electromagnetic
fi elds do not forget to mount the varistor
in parallel on the lock terminal.
KCIN
Illuminated weatherproof Keypad with Remote Electronics 1, 2 or 3 relays
INSTALLATION MANUAL
