CDVI Digicode Series User Manual

PROFIL100EC
Illuminated Mullion Weatherproof Keypad with Remote Electronics
INSTALLATION MANUAL
5
cdvi.com
cdvigroup.com
A. Reset master code
and user codes
1. Enter the master code twice
(1 2 3 4 5 default value master code).
2 beeps are emitted to conrm entry
in programming mode.
2. Press A6 to reset the Master Code
and the User codes.
- One beep is emitted.
- Press on A and B to conrm reset
of all memory of the keypad.
- Wait for two beeps.
- The master code is restored to its default
value 1 2 3 4 5 and all the User codes
are deleted from the keypad.
- Once the reset is completed then the keypad
returns to a stand-by operating mode.
OR
1. Cut the power. Place the jumper on P2.
2. Put the power back.
- Wait approximately 3 seconds.
- Two beeps are emitted to conrm reset
of the keypad.
- Remove P2 jumper.
- The master code is restored to its default
value 1 2 3 4 5 and all the User codes
are deleted from the keypad.
B. Setting code length
1. Enter the master code twice.
(1 2 3 4 5 default value master code).
2 beeps are emitted to conrm entry
in programming mode.
2. Press A4 to program the code length.
- One beep is emitted.
- Press 4 or 5 for the digit code.
- One beep is emitted to conrm
programming of the code length.
3. Press A5 to modify the master code.
- One beep is emitted.
- Enter the new 4 or 5-digits master code.
- One beep is emitted to conrm
programming of the new master code.
4. Press B to exit from
programming mode.
2 beeps are emitted to conrm that the
keypad is in stand-by operating mode.
4 beeps indicate a data computing error.
Default values
- Without codes.
- Illumination time: 10 seconds.
- Relay release time: 1 second.
- Code length: 5-digits.
- Master Code: 1 2 3 4 5.
- Programming security time :
120 secondes.
- Code length for sub master code:
Version 1 relay
(Group 1) = AB,
Version 2 relays
(Group 2) = 13.
Audible signal:
- The buzzer indicates different
audible signals.
- It can be turned off by cutting
the ST1 wire on the remote
electronics.
- 1 short beep: Keypad powered.
- 1 long beep: Data computing
in programming or access
granted.
- 2 short beeps: Enter or Exit
from programming.
- 4 short beeps:
data computing error.
Code length
- The master code and the User
codes can be of 4 or 5-digits
in length.
- All the keypad keys can be used
to program a code.
- The master code and the Pin code
can be of 4 or 5-digits code.
- The master code CAN NOT
be used as a PIN code
(User Pin code).
- To delete a specic User pin Code
replace it by 0 0 0 0 if code
length is 4-digits format or
replace it by 0 0 0 0 0 if the
code is in 5-digits format.
P2 jumper:
Reset master code and user
codes
P3 jumper:
Modication of individual
code by the user

CDVI Digicode Series Specifications

General

Category	Keypad
Manufacturer	CDVI
Series	Digicode Series
IP Rating	IP54
Tamper Output	Yes
Weight	200g
Number of Codes	100
Number of Digits	4 to 8
Operating Voltage	12/24 Vac/dc
Relay Output	1 (NO/NC)
