CDVI Digicode Series User Manual

PROFIL100EC
Illuminated Mullion Weatherproof Keypad with Remote Electronics
INSTALLATION MANUAL
6
cdvi.com
cdvigroup.com
C. Changing the master code
The master code is used only
to enter in programming mode.
1. Enter the master code twice.
(1 2 3 4 5 default value master code).
2 beeps are emitted to conrm
entry in programming mode.
2. Press A5 to modify the master code.
- One beep is emitted.
- Enter the new 4 or 5 digits master code.
- One beep is emitted to conrm
that the master code is programmed.
3. Press B to exit
from the programming mode.
2 beeps are emitted to conrm that
the keypad is in stand-by operating mode.
D. Adding, changing
or deleting a user code
Group 1: From address 00 to address 99,
relay output 1
1. Enter the master code twice
(1 2 3 4 5 default value master code).
2 beeps are emitted to conrm entry
in programming mode.
2. To add a user code, enter the user
location (from 00 to 99).
If the user location is used 4 beeps
are emitted, enter the 4 or 5-digits
User code.
3. To Change a User code enter
the user location.
- 4 beeps are emitted to indicate that
the user location is already programmed.
- Enter a new 4 or 5-digits code.
- A beep is emitted to conrm the new
user code.
4. To delete a User code enter
the user location.
- 4 beeps are emitted.
- Press 0 0 0 0 0 in 5-digits length code
or 0 0 0 0 in 4-digits length code.
- A beep is emitted to conrm the user
code has been deleted.
Note:
If the Pin code is already programmed or is
identical to the master code, then 4 beeps are
emitted. Press B to exit from the programming
mode. 2 beeps are emitted to conrm that the
keypad is in stand-by operating mode.
E. Time outputs
This section allows to program
the illumination time and the Relay
activation time.
1. Enter the master code twice
(1 2 3 4 5 default value master code).
2 beeps are emitted to conrm
entry in programming mode.
2. Press A0 to program the key-in
keypad time and the keys lit time.
1 beep is emitted.
- Enter the time in 10th of second – 10 for
10 seconds up to 99 for 99 seconds
The backlighting dims 10 seconds after
the last keypress or switches off after
entering a valid code.
- Press 00 for permanent illumination keys.
- One beep is emitted to validate the time.
3. Press A1 to program relay 1
output time (door release time).
- 1 beep is emitted.
- For a latched output enter the time
in seconds – 01 for 1 second up to 99
for 99 seconds.
- Press 00 for a toggled output.
- One beep is emitted to validate the time.
4. Press B to exit from
programming mode.
2 beeps are emitted to conrm that
the keypad is in stand-by operating mode.
4 beeps indicate a data computing error.

CDVI Digicode Series Specifications

General

Category	Keypad
Manufacturer	CDVI
Series	Digicode Series
IP Rating	IP54
Tamper Output	Yes
Weight	200g
Number of Codes	100
Number of Digits	4 to 8
Operating Voltage	12/24 Vac/dc
Relay Output	1 (NO/NC)
