CDVI Galeo - Wiring Diagram GALEO 1 Relay Output; GALEO 1 Relay Output Wiring Details

V V
R1
P3
P2
C1 T1 P1 M P2 PX H H + - E
P1 H
V
V V

D - 693 : Remote electronics
P3jumperallows
totheusertomodify
itsownPincode.
Toenablethisfeatureput
thejumperon.
(seeProgrammingsection
intheinstructionmanual)
P2 jumper resets the
keypad to factory default
values.Removethepower
from the keypad then put
thejumper.
(see Programming section
intheinstructionmanual)

12to24VAC
or12to48VDC
Failsafelock

Keypadmode

Request-to-Entermode


White
Brown
Greenorblue
Failsecurelock
Varistor

Accordingtolock
specications

P1request-to-exitinputactivatesrelay1.
P2request-to-exitinputactivatesrelay2.
Latchortoggledoutput.



Whenthecontactisopen
thentherequest-to-enterisdisabled.
Whenthecontactisclosedthenpress
anykeyonthekeypadtoenter.
5
cdvi.se
cdvigroup.com

IlluminatedWeatherproofKeypadwithremoteelectronics
 
 

Inputvoltage12Vto24Vacor12Vto48Vdc

Inputvoltage12Vto24Vacor12Vto48Vdc

N/Ccontactrelay1

Commonrelay1

N/Ocontactrelay1

Request-to-exitinputrelay1

Commonofinput

TimerContact

Whitewirekeypad

Brownwirekeypad

GreenorBluewire(illumination)
